IC697ALG230模拟输入模块 PDF资料
IC697ALG230 是 GE Fanuc（现 Emerson）Series 90-70 PLC 系统中的 8 通道差分模拟量输入基础转换模块，负责将现场模拟信号转换为数字量供 CPU 处理。
产品应用领域（10条）
石油化工反应器温度、压力信号采集
电力行业锅炉、汽轮机参数监控
冶金加热炉温度控制
制药发酵罐过程变量监测
大型 HVAC 中央冷热源系统监控
制造业生产线传感器数据采集
能源管理系统信号采集
水处理过程流量、液位监测
配合 IC697ALG440/441 扩展模块组成完整模拟子系统
各类工业自动化过程控制场合
产品参数（3条）
输入通道：8 路差分输入，每路可独立配置为电压或电流
输入范围：电压 -10V 至 +10V，电流 4-20mA
分辨率：16 位，转换数据以二进制补码格式输出
结尾
IC697ALG230 作为 Series 90-70 系统的模拟量输入前端，承担将现场传感器信号转换为 PLC 可处理数字量的核心功能。
IC697ALG230模拟输入模块 英文介绍
IC697ALG230 is an 8-channel differential analog input basic conversion module in GE Fanuc (now Emerson) Series 90-70 PLC system, responsible for converting on-site analog signals into digital quantities for CPU processing.
Product application areas (10 items)
Collection of temperature and pressure signals for petrochemical reactors
Monitoring of boiler and turbine parameters in the power industry
Temperature control of metallurgical heating furnace
Monitoring of process variables in pharmaceutical fermentation tanks
Monitoring of large HVAC central heating and cooling systems
Sensor data collection for manufacturing production lines
Energy management system signal acquisition
Flow and liquid level monitoring in water treatment process
Cooperate with the IC697ALG440/441 expansion module to form a complete simulation subsystem
Various industrial automation process control scenarios
Product parameters (3 items)
Input channel: 8 differential inputs, each independently configurable as voltage or current
Input range: Voltage -10V to+10V, Current 4-20mA
Resolution: 16 bits, convert data to output in binary complement format
ending
IC697ALG230 serves as the analog input front-end for Series 90-70 systems, responsible for the core function of converting on-site sensor signals into digital quantities that can be processed by PLC.
IC697ALG230模拟输入模块 产品图片
