BOBST 0701249701 723-LW 11246054控制板 PDF资料
BOBST 0701249701 723-LW 11246054 是用于博斯特印刷包装设备的光电检测模块，主要负责在线检测与控制。
产品特点
长窗口检测：检测行程范围较宽，适应不同工况。
红外光源抗干扰：采用红外光运行，可抵抗环境光干扰。
灵敏度可调：档位灵敏度可调，适配多种纸张材料。
双张精准识别：能准确识别双张材料，避免设备卡纸。
高速信号反馈：信号反馈速度快，匹配设备高速产能。
双重输出模式：兼容设备主控电路，对接方便。
密封防护结构：防止油墨和粉尘进入内部。
抗震外壳：适应机械振动工况。
宽工作温度：在车间环境下可稳定运行。
标准安装尺寸：便于原位拆装更换。
产品应用领域
印刷机色标检测：用于印刷套准中的色标识别。
模切机送料检测：用于模切设备的进纸检测与控制。
卷材纠偏系统：边缘检测能力适用于卷材纠偏。
包装设备生产线：配合博斯特包装设备实现板材在线检测。
纸板双张检测：在进纸环节防止双张进入设备。
材料短缺监测：实时监控物料，缺料时自动发出信号。
高速生产线检测：满足高速生产条件下的实时检测要求。
印刷包装设备：专为博斯特系列印刷机、模切机设计。
产品参数
产品类型：光电检测模块。
光源类型：红外光源。
输出方式：双输出模式，兼容主控电路。
综上，BOBST 0701249701 723-LW 11246054 光电检测模块是博斯特印刷包装设备送料检测环节的核心部件，以红外检测和双张识别为主要功能，保障生产线连续稳定运行。
BOBST 0701249701 723-LW 11246054控制板 英文介绍
BOBST 0701249701 723-LW 11246054 is a photoelectric detection module used in Bosch printing and packaging equipment, mainly responsible for online detection and control.
Product Features
Long window detection: The detection range is wide and suitable for different working conditions.
Infrared light source anti-interference: It operates with infrared light and can resist environmental light interference.
Sensitivity adjustable: The gear sensitivity is adjustable and suitable for various paper materials.
Double sheet accurate recognition: It can accurately identify double sheet materials and avoid equipment jamming.
High speed signal feedback: The signal feedback speed is fast, matching the high-speed production capacity of the equipment.
Dual output mode: compatible with the main control circuit of the device, easy to connect.
Sealed protective structure: prevents ink and dust from entering the interior.
Seismic resistant shell: Suitable for mechanical vibration conditions.
Wide working temperature: It can operate stably in the workshop environment.
Standard installation size: easy to disassemble and replace in situ.
Product application areas
Printing machine color code detection: used for color code recognition in printing registration.
Die cutting machine feeding detection: used for feeding detection and control of die cutting equipment.
Roll correction system: The edge detection capability is suitable for roll correction.
Packaging equipment production line: Cooperate with Bost packaging equipment to achieve online detection of sheet metal.
Cardboard double sheet detection: prevent double sheets from entering the equipment during the feeding process.
Material shortage monitoring: Real time monitoring of materials, automatically sending signals when there is a shortage.
High speed production line inspection: meets real-time inspection requirements under high-speed production conditions.
Printing and packaging equipment: specially designed for the Bobst series printing machines and die-cutting machines.
Product Specifications
Product type: photoelectric detection module.
Light source type: infrared light source.
Output mode: Dual output mode, compatible with the main control circuit.
In summary, the BOBST 0701249701 723-LW 11246054 photoelectric detection module is the core component of the material feeding detection process in Bosch printing and packaging equipment. Its main functions are infrared detection and double sheet recognition, ensuring the continuous and stable operation of the production line.
BOBST 0701249701 723-LW 11246054控制板 产品图片
