Omron ZW-7000T位移传感器   PDF资料

1.产 品 资 料 介 绍：

Omron ZW-7000T 位移传感器简介

产品特点

1. 采用白光共焦测量原理，投光与受光同轴设计，可在测量范围全领域准确测量同一位置。

2. 不受被测物材质和表面状态限制，镜面、粗糙面、曲面、倾斜面及透明体均可稳定测量。

3. 测量周期最短可达20μs，无需平均化处理即可忠实再现工件形状轮廓。

4. 传感头光点直径最小可达50μm，适合微小部品和狭小区域的精密测量。

5. 内置EtherCAT接口，可与NX/NJ系列控制器高速同步，实现移动中的精确测量。

产品应用领域

1. 智能手机盖板玻璃曲面形状检测

2. 半导体晶圆厚度均匀性监测

3. 汽车车身面板变形与缺陷检测

4. 精密机械零件尺寸公差检测

5. 电子元件引脚高度与间隙测量

6. 透明薄膜与玻璃厚度测量

7. 3D曲面玻璃轮廓扫描

8. 粗糙面工件平坦度测量

9. 微小部品间隙与位置检测

10. 生产线在线高速品质检测

产品参数

1. 产品型号：ZW-7000T（控制器），适用传感头 ZW-S70系列

2. 测量周期：20μs ~ 400μs；电源：DC 24V（21.6~26.4V）；输出类型：NPN/PNP通用

3. 静态分辨率：0.25μm；防护等级：控制器IP20，传感头IP40

总结：Omron ZW-7000T 是ZW-7000系列光纤同轴位移传感器的EtherCAT控制器，配合专用传感头可实现镜面、粗糙面、透明体等多种材质的高速高精度非接触测量，适用于电子制造、半导体及精密加工等领域的在线检测。

Omron ZW-7000T位移传感器  英文介绍

Introduction to Omron ZW-7000T Displacement Sensor

Product Features

Adopting the principle of white light confocal measurement, the projection and reception are designed coaxially, which can accurately measure the same position in the entire measurement range.

Unrestricted by the material and surface condition of the object being measured, mirror surfaces, rough surfaces, curved surfaces, inclined surfaces, and transparent bodies can all be measured stably.

The measurement cycle can be as short as 20 μ s, and the shape and contour of the workpiece can be faithfully reproduced without averaging processing.

The minimum diameter of the sensing head light spot can reach 50 μ m, suitable for precise measurement of small components and narrow areas.

Built in EtherCAT interface, capable of high-speed synchronization with NX/NJ series controllers, enabling precise measurement during movement.

Product application areas

Shape detection of curved surface of smartphone cover glass

Monitoring of semiconductor wafer thickness uniformity

Deformation and Defect Detection of Automotive Body Panels

Dimensional tolerance testing of precision mechanical parts

Measurement of Pin Height and Gap of Electronic Components

Measurement of Transparent Film and Glass Thickness

3D curved glass contour scanning

Measurement of flatness of rough surface workpieces

Gap and position detection of small components

Online high-speed quality inspection of production line

Product Specifications

Product model: ZW-7000T (controller), suitable for sensing head ZW-S70 series

Measurement cycle: 20 μ s~400 μ s; Power supply: DC 24V (21.6-26.4V); Output type: NPN/PNP universal

Static resolution: 0.25 μ m; Protection level: Controller IP20, Sensor head IP40

Summary: Omron ZW-7000T is an EtherCAT controller for ZW-7000 series fiber coaxial displacement sensors. With a dedicated sensing head, it can achieve high-speed and high-precision non-contact measurement of various materials such as mirrors, rough surfaces, and transparent bodies. It is suitable for online detection in fields such as electronic manufacturing, semiconductors, and precision machining.

Omron ZW-7000T位移传感器  产品图片
