PPC7508-YB01A触摸屏面板  PDF资料

1.产 品 资 料 介 绍：

PPC7508-YB01A 是一款工业触摸屏面板，物料编码为 3BSE076359R1，部分供应商也将其归类为输入模块或工业控制模块。

产品应用领域

1. 工业自动化控制系统的人机界面

2. PLC 与数控设备的操作终端

3. 冶金、化工等流程工业的操作站

4. 电力系统与变电站自动化

5. 变频器密集的工厂环境

6. 戴手套或使用金属笔头点击的工业操作场景

7. 老旧 HMI 设备的替换与维护

产品特点

1. 采用四线电阻触控架构，支持戴手套或使用触控笔操作

2. 结构精简，无多点触控或复杂驱动，材料成本较低

3. 固定 80Hz 驱动频率，规避高频切换带来的 EMI 辐射

4. 具备较强的抗静电干扰能力，实测可达 ±8kV

5. 在 -20°C 至 70°C 宽温环境下可稳定运行，长期使用坐标漂移小

产品参数

1. 触控类型：四线电阻屏，X/Y 方向线性度误差 ±1.2%

2. 采样率：80Hz，响应延迟约 80ms

3. 工作温度：-20°C 至 +70°C

4. 防护与认证：部分资料显示 IP65 防护等级，具备 CE、UL 等认证

结语

ABB PPC7508-YB01A 是一款面向工业 HMI 场景的四线电阻触摸屏面板，设计上侧重可靠性与兼容性而非触控体验。其电阻屏结构使其在戴手套、油污或使用触控笔的工业操作环境中具备实际优势，适合作为老旧数控终端或 PLC 操作站的替换组件。

PPC7508-YB01A触摸屏面板   英文介绍

PPC7508-YB01A is an industrial touch screen panel with material code 3BSE076359R1. Some suppliers also classify it as an input module or industrial control module.

Product application areas

Human machine interface of industrial automation control system

Operation terminals for PLC and CNC equipment

Operation stations for process industries such as metallurgy and chemical engineering

Power System and Substation Automation

Factory environment with dense frequency converters

Industrial operation scenarios where gloves are worn or metal pen tips are used for clicking

Replacement and maintenance of old HMI equipment

Product Features

Adopting a four wire resistive touch architecture, supporting glove wearing or stylus operation

Simplified structure, no multi touch or complex drivers, low material cost

Fixed driving frequency of 80Hz to avoid EMI radiation caused by high-frequency switching

Has strong anti-static interference ability, measured to reach ± 8kV

Stable operation in a wide temperature range of -20 ° C to 70 ° C, with minimal coordinate drift for long-term use

Product Specifications

Touch type: Four wire resistive screen, X/Y direction linearity error ± 1.2%

Sampling rate: 80Hz, response delay of approximately 80ms

Working temperature: -20 ° C to+70 ° C

Protection and certification: Some information shows IP65 protection level, with CE, UL and other certifications

Conclusion

ABB PPC7508-YB01A is a four wire resistive touch screen panel designed for industrial HMI scenarios, with a focus on reliability and compatibility rather than touch experience. Its resistive screen structure gives it practical advantages in industrial operating environments such as wearing gloves, oil stains, or using a stylus, making it suitable as a replacement component for old CNC terminals or PLC operating stations.

PPC7508-YB01A触摸屏面板 产品图片
