ACS CM-3-A-E-M3-H4控制器模块 PDF资料
ACS CM-3-A-E-M3-H4 是 ACS Motion Control 的 SPiiPlus CM3 系列三轴运动控制器模块。
产品应用领域
工业自动化多轴运动控制
CNC 数控系统轴控制
半导体制造设备精密定位
电子组装与贴片设备
实验室自动化与测试设备
机器人关节驱动控制
通用 OEM 设备运动控制集成
产品特点
三轴控制能力，支持步进/方向驱动、直流伺服及无刷电机
内置 5A 持续 / 10A 峰值驱动能力
支持 Sin/Cos 编码器、霍尔编码器（正交、AB 等）多种反馈类型
所有输入输出均光电隔离，每个连接器可独立供电（5V 或 24V）
支持 RS232 与以太网 10/100 通信，可通过软件连接配置和调试
具备 2 路 HSSI（高速串行接口），支持手轮 PEG 输入
支持三相机或单相机供电模式
产品参数
型号：SPiiPlus CM3-A-E-M3（对应 CM-3-A-E-M3-H4 配置）
轴数：3 轴（XYA 等）
驱动能力：持续 5A，峰值 10A
通信接口：RS232、Ethernet 10/100
反馈类型：Sin/Cos 编码器、霍尔（正交/AB）、3 路 Sin-Cos 编码器输入
高速接口：2 路 HSSI
供电：控制单元外部 24V 供电（J17 接口），电机驱动支持三相机或单相机输入
软件状态：官方已停产（Discontinued），不再提供支持，但软件仍可获取
结语
ACS SPiiPlus CM3 系列是面向多轴精密运动控制的集成式控制器模块，CM-3-A-E-M3-H4 配置具备三轴驱动、多类型编码器反馈和双通信接口，适用于对定位精度和集成度要求较高的工业自动化场景。
ACS CM-3-A-E-M3-H4控制器模块 英文介绍
ACS CM-3-A-E-M3-H4 is the SPiiPlus CM3 series three-axis motion controller module of ACS Motion Control.
Product application areas
Multi axis motion control in industrial automation
CNC numerical control system axis control
Precision positioning of semiconductor manufacturing equipment
Electronic assembly and surface mount equipment
Laboratory Automation and Testing Equipment
Robot Joint Drive Control
General OEM equipment motion control integration
Product Features
Three axis control capability, supporting stepper/directional drive, DC servo, and brushless motor
Built in 5A continuous/10A peak driving capability
Support Sin/Cos encoder, Hall encoder (orthogonal, AB, etc.) with multiple feedback types
All inputs and outputs are optically isolated, and each connector can be independently powered (5V or 24V)
Supports RS232 and Ethernet 10/100 communication, can be configured and debugged through software connection
Equipped with 2 HSSI (high-speed serial interfaces) and supporting PEG input for handwheel
Support three camera or single camera power supply mode
Product Specifications
Model: SPiiPlus CM3-A-E-M3 (corresponding to CM-3-A-E-M3-H4 configuration)
Number of axes: 3 axes (XYA, etc.)
Driving capability: continuous 5A, peak 10A
Communication interface: RS232, Ethernet 10/100
Feedback type: Sin/Cos encoder, Hall (orthogonal/AB), 3-channel Sin Cos encoder input
High speed interface: 2-channel HSSI
Power supply: 24V external power supply for control unit (J17 interface), motor drive supports three camera or single camera input
Software status: Officially discontinued and no longer supported, but the software can still be accessed
Conclusion
The ACS SPiiPlus CM3 series is an integrated controller module designed for multi axis precision motion control. The CM-3-A-E-M3-H4 configuration features three-axis drive, multi type encoder feedback, and dual communication interfaces, making it suitable for industrial automation scenarios that require high positioning accuracy and integration.
