Yaskawa JUSP-RCP01AAD电源板 PDF资料
Yaskawa JUSP-RCP01AAD 是安川（Yaskawa）伺服与机器人系统专用的伺服控制电源模块，主要用于为伺服驱动器或机器人控制基板提供稳定的直流工作电源。
产品应用领域
工业机器人控制系统（如 XRC、NX100、YRC1000 控制柜）
安川伺服驱动系统配套供电（CACR-SR/SV/UP/CSL 等系列）
数控机床（CNC）伺服控制单元
自动化生产线伺服电机驱动供电
电子制造设备（贴片机、精密加工）
汽车制造与焊接机器人系统
物料搬运与搬运机器人控制柜
产品特点
为伺服控制电路提供多路直流输出（+5V、+7V、±15V），满足控制基板供电需求
采用单相 200/220VAC 输入，适应工业现场标准电源
配备 +5V 输出指示灯（绿色 LED），便于快速判断工作状态
模块化设计，安装于控制柜内，便于维护更换
常见故障包括无显示、烧保险、输出电压低等，是控制器黑屏或伺服报警的常见排查对象
产品参数
型号：JUSP-RCP01AAD
输入：单相 200~220VAC，允许波动 AC170V~242V，频率 50/60Hz（48~62Hz）
输出：+5V（5A）、+7V（2.5A）、+15V（1.3A）、-15V（0.6A）
结语
JUSP-RCP01AAD 是安川早期机器人及伺服系统中承担控制电源分配的关键模块，常见于 XRC、NX100 等经典控制柜。
Yaskawa JUSP-RCP01AAD电源板 英文介绍
Yaskawa JUSP-RCP01AAD is a servo control power module dedicated to Yaskawa servo and robot systems, mainly used to provide stable DC working power for servo drivers or robot control substrates.
Product application areas
Industrial robot control systems (such as XRC, NX100, YRC1000 control cabinets)
Yaskawa servo drive system supporting power supply (CACR-SR/SV/UP/CSL series, etc.)
CNC servo control unit
Automated production line servo motor drive power supply
Electronic manufacturing equipment (SMT machine, precision machining)
Automotive Manufacturing and Welding Robot System
Material handling and handling robot control cabinet
Product Features
Provide multiple DC outputs (+5V,+7V, ± 15V) for servo control circuits to meet the power supply requirements of the control board
Adopting single-phase 200/220V AC input, suitable for industrial site standard power supply
Equipped with+5V output indicator light (green LED) for quick judgment of working status
Modular design, installed inside the control cabinet for easy maintenance and replacement
Common faults include no display, fuse burning, low output voltage, etc., which are common troubleshooting objects for controller black screen or servo alarm
Product Specifications
Model: JUSP-RCP01AAD
Input: Single phase 200~220V AC, allowable fluctuation AC170V~242V, frequency 50/60Hz (48~62Hz)
Output:+5V (5A),+7V (2.5A),+15V (1.3A), -15V (0.6A)
Conclusion
JUSP-RCP01AAD is a key module responsible for controlling power distribution in early Yaskawa robots and servo systems, commonly found in classic control cabinets such as XRC and NX100.
