GE 5371196-2通讯模块 PDF资料
GE 5371196-2 通讯模块
产品特点
属于 GE 超声系统的 GFS 板组件，用于 Logiq S7、Logiq S8 等型号。
作为主网关板，负责系统内部信号通信与数据处理。
与探头/换能器部分配合工作，支持超声成像信号传输。
属于医疗超声设备的核心电路板组件，非通用工业通讯模块。
通常作为备件提供，带保修，用于设备维修替换。
应用领域
GE Logiq S7 超声系统。
GE Logiq S8 超声系统。
GE Logiq E 超声系统。
医疗超声成像设备的维修与备件替换。
医院及影像中心的超声设备维护。
总结
GE 5371196-2 是 GE Logiq 系列超声系统的 GFS 板组件，主要用于医疗超声设备的信号通信与成像处理，属于设备维修备件。
GE 5371196-2通讯模块 英文介绍
GE 5371196-2 Communication Module
Product Features
GFS board component belonging to GE ultrasound system, used for Logiq S7, Logiq S8 and other models.
As the main gateway board, responsible for internal signal communication and data processing of the system.
Work in conjunction with the probe/transducer section to support ultrasound imaging signal transmission.
The core circuit board component of medical ultrasound equipment, not a general industrial communication module.
Usually provided as spare parts, with warranty, for equipment repair and replacement.
Application Areas
GE Logiq S7 ultrasound system.
GE Logiq S8 ultrasound system.
GE Logiq E ultrasound system.
Maintenance and replacement of medical ultrasound imaging equipment.
Maintenance of ultrasound equipment in hospitals and imaging centers.
Summary
GE 5371196-2 is a GFS board component of the GE Logiq series ultrasound system, mainly used for signal communication and imaging processing of medical ultrasound equipment, and is a spare part for equipment maintenance.
GE 5371196-2通讯模块 产品图片
