AE 3155094-003 A射频匹配模块 PDF资料
AE 3155094-003 A 射频匹配模块
产品特点
属于 AE Fixed Match 固定匹配器，配套 AE RFG2000-2V 射频电源使用。
固定匹配设计，无需调谐操作，简单便捷。
无需独立供电，体积小，占用机台空间少。
能减少信号反射，降低射频损耗，提升功率利用效率。
应用领域
半导体制造产线中的射频功率匹配。
半导体封装与测试工艺。
光伏产线中的射频应用。
等离子体刻蚀工艺。
等离子体增强化学气相沉积。
物理气相沉积工艺。
腔体清洗工艺。
平板显示器生产线。
MEMS 器件制造。
配套 AE RFG2000-2V 射频电源的机台系统。
总结
AE 3155094-003 A 是一款配套 RFG2000-2V 电源使用的固定射频匹配器，操作简单、损耗低，主要服务于半导体、封测、光伏等领域的射频功率传输。
AE 3155094-003 A RF matching module
Product Features
Belonging to AE Fixed Match, it is used in conjunction with AE RFG2000-2V RF power supply.
Fixed matching design, no need for tuning operation, simple and convenient.
No need for independent power supply, small size, and less space occupation of the machine.
It can reduce signal reflection, lower RF loss, and improve power utilization efficiency.
Application Areas
RF power matching in semiconductor manufacturing production lines.
Semiconductor packaging and testing process.
RF applications in photovoltaic production lines.
Plasma etching process.
Plasma enhanced chemical vapor deposition.
Physical vapor deposition process.
Chamber cleaning process.
Flat panel display production line.
Manufacturing of MEMS devices.
Machine system with AE RFG2000-2V RF power supply.
Summary
AE 3155094-003 A is a fixed RF matching device used with RFG2000-2V power supply. It is easy to operate and has low losses, mainly serving RF power transmission in the fields of semiconductor, packaging and testing, photovoltaics, etc.
