REXROTH HMS01.1N-W0070-A-07-NNNN伺服驱动器 PDF资料
REXROTH HMS01.1N-W0070-A-07-NNNN 伺服驱动器
HMS01.1N-W0070-A-07-NNNN 是博世力士乐（Bosch Rexroth）IndraDrive M 系列的一款单轴逆变器（伺服驱动器）。它需要配合电源模块从直流母线取电，专门用于控制交流伺服电机，实现精确的速度、位置和转矩控制。
产品特点（10条）
博世力士乐 IndraDrive M 系列单轴逆变器
紧凑型设计，适合多轴应用，节省柜内空间
内部空气冷却，内置鼓风机
高功率密度，提供 70 A 最大电流
宽泛的直流母线电压输入范围，适应多种电源配置
精确控制交流伺服电机的速度、位置和转矩
适用于机床、印刷、机器人和物料搬运等工业自动化场景
IP20 防护等级，需安装在控制柜内
单轴设计版本 1，带有集成鼓风机
可通过直流母线并联，实现多轴共直流母线方案
产品参数（5条）
型号：HMS01.1N-W0070-A-07-NNNN
品牌：Bosch Rexroth（博世力士乐）/ IndraDrive
最大输出电流：70.7 A（4kHz 开关频率下）
连续输出电流：42.4 A
直流母线标称电压：DC 700 V，输入范围 254–750 V
总的来说，HMS01.1N-W0070-A-07-NNNN 是一款用于 IndraDrive 系统的单轴伺服逆变器模块，具备 70 A 峰值电流输出能力，适合中高功率伺服应用
REXROTH HMS01.1N-W0070-A-07-NNNN伺服驱动器 英文介绍
REXROTH HMS01.1N-W0070-A-07-NNN servo driver
HMS01.1N-W0070-A-07-NNN is a single axis inverter (servo drive) from Bosch Rexroth IndraDrive M series. It needs to be powered from the DC bus in conjunction with a power module, specifically designed to control AC servo motors and achieve precise speed, position, and torque control.
Product features (10 items)
Bosch Rexroth IndraDrive M series single axis inverter
Compact design, suitable for multi axis applications, saves cabinet space
Internal air cooling, built-in blower
High power density, providing a maximum current of 70 A
Wide DC bus voltage input range, suitable for various power supply configurations
Accurately control the speed, position, and torque of AC servo motors
Suitable for industrial automation scenarios such as machine tools, printing, robots, and material handling
IP20 protection level, to be installed inside the control cabinet
Single axis design version 1 with integrated blower
Multiple axis common DC bus scheme can be achieved through parallel connection of DC bus
Product parameters (5 items)
Model: HMS01.1N-W0070-A-07-NNN
Brand: Bosch Rexroth/IndraDrive
Maximum output current: 70.7 A (at 4kHz switching frequency)
Continuous output current: 42.4 A
DC bus nominal voltage: DC 700 V, input range 254-750 V
Overall, HMS01.1N-W0070-A-07-NNN is a single axis servo inverter module for IndraDrive systems, with a peak current output capability of 70 A, suitable for medium to high power servo applications
REXROTH HMS01.1N-W0070-A-07-NNNN伺服驱动器 产品图片
