RENISHAW ACC2-2自动转换控制单元 PDF资料
RENISHAW ACC2-2 自动转换控制单元
ACC2-2 是雷尼绍（Renishaw）ACR1 自动探针交换系统的核心控制单元，负责协调 CMM 控制器与 ACR1 交换架之间的通信，并处理测头信号的多路复用与接口。
产品特点（10条）
Renishaw 原厂制造，属于 ACR1 自动交换系统的智能控制部分
处理 CMM 控制器与 ACR1 交换架之间的通信
多路复用并接口测头和基准探针信号
支持 IEEE 488（并行）通信方式
支持 RS232（串行）通信方式，波特率 300–19200
支持独立运行模式，无需通信链接即可操作交换架
配备前面板 LED 状态指示，涵盖电源、探针就位、交换架状态及错误指示
支持 PICS 信号输入/输出，用于雷尼绍设备间实时通信
具备错误检测与恢复机制，支持复位操作
功能上兼容 ACC1 和 ACC2 安装
产品参数（5条）
型号：ACC2-2（备件号 A-1520-0101 / A-1520-0100）
品牌：RENISHAW（雷尼绍）
电源：100–240 VAC，47–66 Hz，功耗 50W
通信接口：RS232、IEEE 488（24 路）、PICS 输入/输出（9 路 D 型）
尺寸：88（高）× 289.3（宽）× 220（深）mm，重量约 3.85 kg
总的来说，RENISHAW ACC2-2 是一款用于 ACR1 自动探针交换系统的控制单元，负责通信协调与信号处理，支持多种通信方式和独立运行模式
RENISHAW ACC2-2自动转换控制单元 英文介绍
RENISHAW ACC2-2 Automatic Conversion Control Unit
ACC2-2 is the core control unit of Renishaw ACR1 automatic probe exchange system, responsible for coordinating communication between CMM controller and ACR1 exchange rack, and handling the multiplexing and interface of probe signals.
Product features (10 items)
Renishaw factory manufactured, belonging to the intelligent control part of ACR1 automatic exchange system
Handling communication between CMM controller and ACR1 exchange rack
Multiplexing and interfacing probe and reference probe signals
Supports IEEE 488 (parallel) communication method
Supports RS232 (serial) communication mode, baud rate 300-19200
Support independent operation mode, no communication link required to operate the switch rack
Equipped with front panel LED status indicator, covering power supply, probe in place, exchange rack status, and error indication
Supports PICS signal input/output for real-time communication between Renishaw devices
Equipped with error detection and recovery mechanisms, supporting reset operations
Functionally compatible with ACC1 and ACC2 installations
Product parameters (5 items)
Model: ACC2-2 (spare part numbers A-1520-0101/A-1520-0100)
Brand: RENISHAW
Power supply: 100-240 VAC, 47-66 Hz, power consumption 50W
Communication interface: RS232, IEEE 488 (24 channels), PICS input/output (9-channel D-type)
Dimensions: 88 (height) x 289.3 (width) x 220 (depth) mm, weight approximately 3.85 kg
Overall, RENISHAW ACC2-2 is a control unit for ACR1 automatic probe exchange system, responsible for communication coordination and signal processing, supporting multiple communication modes and independent operation modes
RENISHAW ACC2-2自动转换控制单元 产品图片
