FANUC A16B-1211-0272/03B印刷电路板 PDF资料
FANUC A16B-1211-0272/03B 印刷电路板
A16B-1211-0272/03B 是发那科（FANUC）System 10/11 系列数控系统中的一块双通道数字轴控制电路板，属于附加轴卡，用于扩展伺服轴的控制能力。
产品特点（10条）
FANUC 原厂制造，日本生产
属于 System 10/11 系列轴控制 PCB
双通道设计，可控制 2 个伺服轴
作为附加轴卡，与主控制板配合使用
适配 6057 及 6058 系列数字 AC 伺服驱动器
支持脉冲编码器反馈信号输入
采用通孔（非 SMT）工艺制造
板卡版本为 /03B，需核对匹配
可通过交换、维修方式获取
该型号已停产，属经典维护备件
产品参数（5条）
型号：A16B-1211-0272/03B
品牌：FANUC（发那科）
类型：双通道数字轴控制电路板
适配系统：FANUC System 10、11、11A、11M、11T、11F
适配驱动器：6057 / 6058 系列
总的来说，FANUC A16B-1211-0272/03B 是一款用于 System 10/11 数控系统的双轴控制电路板，主要承担伺服轴的位置指令传输与编码器反馈处理
FANUC AI6B-1211-0272/03B印刷电路板 英文介绍
FANUC A16B-1211-0272/03B Printed Circuit Board
A16B-1211-0272/03B is a dual channel digital axis control circuit board in the FANUC System 10/11 series CNC system. It is an additional axis card used to expand the control capability of servo axes.
Product features (10 items)
FANUC original factory manufacturing, produced in Japan
Belonging to the System 10/11 series axis control PCB
Dual channel design, capable of controlling 2 servo axes
As an additional axle card, used in conjunction with the main control board
Compatible with 6057 and 6058 series digital AC servo drives
Support pulse encoder feedback signal input
Manufacturing using through-hole (non SMT) technology
The board version is/03B, matching needs to be verified
Can be obtained through exchange and repair methods
This model has been discontinued and is a classic maintenance spare part
Product parameters (5 items)
Model: A16B-1211-0272/03B
Brand: FANUC
Type: Dual channel digital axis control circuit board
Adaptation System: FANUC System 10, 11, 11A, 11M, 11T, 11F
Compatible Drivers: 6057/6058 Series
Overall, FANUC A16B-1211-0272/03B is a dual axis control circuit board used in System 10/11 CNC systems, mainly responsible for transmitting servo axis position commands and encoder feedback processing
FANUC A16B-1211-0272/03B印刷电路板 产品图片
