DELTA eTCH-7ET触摸屏面板 PDF资料
DELTA CONTROLS eTCH-7ET 触摸屏面板
eTCH-7ET 是加拿大 Delta Controls 公司 enteliTOUCH 系列的一款 7 英寸彩色触摸屏人机界面，主要用于楼宇自动化系统（BAS）的监控与管理，支持 BACnet 通信协议。
产品特点（10条）
Delta Controls 原厂制造，属于 enteliTOUCH 系列
7 英寸高分辨率宽屏彩色 LCD 触摸屏，无需触针操作
支持 BACnet 协议，通过以太网与 BAS 控制器通信
可配合 enteliMESH 实现无线通信，作为无线协调器
支持用户自定义图形界面，可个性化设计监控画面
可显示并确认报警、修改日程表与日历
支持多用户及密码权限设置，限制访问级别
固件可通过网络或 USB 驱动器升级
内置温度传感器，可选配湿度与人体感应传感器
支持墙面或控制盘箱表面安装，适用于新建及改造项目
产品参数（5条）
型号：eTCH-7ET（enteliTOUCH with Ethernet and Temperature）
品牌：Delta Controls
显示：7 英寸触摸屏 LCD，800 × 480 像素（WVGA），16 位色
通信接口：以太网（BACnet/IP、BACnet Ethernet），可选 RS-485（BACnet MS/TP）
电源：24 VAC 或 10–28 VDC
总的来说，DELTA eTCH-7ET 是一款面向楼宇自控系统的 7 英寸触摸屏操作面板，兼具图形化监控、报警确认、日程管理等功能，适合用于空调、锅炉、冷水机组等设备的运行监视与设定。
DELTA eTCH-7ET触摸屏面板 英文介绍
DELTA Controls eTCH-7ET Touch Screen Panel
ETCH-7ET is a 7-inch color touch screen human-machine interface from Delta Controls Canada's enteliTOUCH series, mainly used for monitoring and management of Building Automation Systems (BAS), supporting BACnet communication protocol.
Product features (10 items)
Delta Controls is manufactured by the original factory and belongs to the enteliTOUCH series
7-inch high-resolution widescreen color LCD touch screen, no need for stylus operation
Support BACnet protocol, communicate with BAS controller through Ethernet
Can be used in conjunction with enteliMESH to achieve wireless communication as a wireless coordinator
Support user-defined graphical interface and personalized design of monitoring screens
Can display and confirm alarms, modify schedules and calendars
Support multi-user and password permission settings, restrict access levels
Firmware can be upgraded through network or USB drive
Built in temperature sensor, optional humidity and human body sensing sensors
Support wall or control panel box surface installation, suitable for new construction and renovation projects
Product parameters (5 items)
Model: eTCH-7ET (enteliTOUCH with Ethernet and Temperature)
Brand: Delta Controls
Display: 7-inch touchscreen LCD, 800 × 480 pixels (WVGA), 16 bit color
Communication interface: Ethernet (BACnet/IP, BACnet Ethernet), optional RS-485 (BACnet MS/TP)
Power supply: 24 VAC or 10-28 VDC
Overall, DELTA eTCH-7ET is a 7-inch touchscreen operation panel designed for building automation systems, which combines graphical monitoring, alarm confirmation, schedule management, and other functions. It is suitable for monitoring and setting the operation of equipment such as air conditioning, boilers, and chillers.
DELTA eTCH-7ET触摸屏面板 产品图片
