ORIENTAL VHR540CM-GVH 伺服电机 PDF资料
1.产 品 资 料 介 绍：
ORIENTAL VHR540CM-GVH 是一款40W级交流调速电机系统组件，包含VHR540CM-GVH电机与配套减速机，适用于需要双向旋转与速度调节的工业场合。以下是该型号的核心特点与应用领域：
产品特点
输出功率40W，适配单相220/230VAC电源供电。
采用可逆式交流电机设计，支持正反转双向旋转控制。
搭配平行轴减速机，减速比7.5:1，输出扭矩达2.2N·m。
调速范围宽，50Hz下12~186r/min，60Hz下12~213r/min。
电机与减速机组合供货，配套ES02调速控制器组成完整驱动单元。
绝缘等级Class B，符合UL、CSA、CCC、CE等多项安全标准。
环境适应性强，工作温度-10℃~40℃，防护等级IP20。
支持内部电位器与外部电位器两种调速方式，可设置两档转速。
应用领域
传送带与输送线的速度可调驱动。
包装机械中的物料输送与定位。
自动化装配线上的旋转工作台驱动。
食品加工设备中的间歇式运转控制。
医疗设备中的往复运动机构。
印刷机械中的纸张输送与对齐。
小型实验装置中的速度可控旋转台。
需要频繁正反转切换的轻载工业设备。
结尾
综上所述，ORIENTAL VHR540CM-GVH 作为一套成熟的40W级交流调速驱动方案，动力输出平稳、调速灵活，适合各类中小型工业自动化设备的速度控制与正反转应用
ORIENTAL VHR540CM-GVH 伺服电机 英文介绍
ORIENTIAL VHR540CM-GFH is a 40W level AC speed regulating motor system component, which includes VHR540CM-GFH motor and matching reducer, suitable for industrial applications that require bidirectional rotation and speed regulation. The following are the core features and application areas of this model:
Product Features
Output power of 40W, compatible with single-phase 220/230VAC power supply.
Adopting reversible AC motor design, supporting bidirectional rotation control in both forward and reverse directions.
Paired with a parallel axis reducer, the reduction ratio is 7.5:1, and the output torque reaches 2.2N · m.
Wide speed range, 12-186r/min at 50Hz and 12-213r/min at 60Hz.
The motor and reducer are supplied in combination, and the ES02 speed controller is used to form a complete drive unit.
Insulation class B, compliant with multiple safety standards such as UL, CSA, CCC, CE, etc.
Strong environmental adaptability, working temperature -10 ℃~40 ℃, protection level IP20.
Supports two speed control modes: internal potentiometer and external potentiometer, and can set two speeds.
Application Domain
The speed of the conveyor belt and conveyor line can be adjusted for driving.
Material conveying and positioning in packaging machinery.
Rotating worktable drive on automated assembly line.
Intermittent operation control in food processing equipment.
The reciprocating motion mechanism in medical equipment.
Paper conveying and alignment in printing machinery.
A speed controllable rotating table in a small experimental setup.
Light load industrial equipment that requires frequent forward and reverse switching.
ending
In summary, ORIENTAL VHR540CM-GFH, as a mature 40W level AC speed regulation drive solution, has stable power output and flexible speed regulation, making it suitable for speed control and forward/reverse applications of various small and medium-sized industrial automation equipment
ORIENTAL VHR540CM-GVH 伺服电机 产品图片
