TEKTRONIX 7035-172-04A 继电器开关卡 PDF资料
1.产 品 资 料 介 绍：
TEKTRONIX 7035-172-04A 是一款高密度多路复用继电器开关卡，适配7001/7002开关主机，用于多通道信号切换测试，切换稳定、通道密度高。以下是该型号的核心特点与应用领域：
产品特点
搭载9组独立1×4多路切换通道，最多切换18路输入信号。
采用双刀A型触点，同步切换高低两路信号，适配差分信号测量。
单通道支持60VDC/30V交流信号，切换电流1A，负载30VA。
通道漏电流低于100pA，弱信号测试无明显干扰偏移。
继电器吸合时长仅3ms，切换速度达100通道每秒。
配备标准96针DIN公头连接器，批量接线便捷整齐。
通道间隔离度高，通道电容低，减少信号串扰失真。
内置工业电磁继电器，触点寿命长，长期测试可靠性高。
应用领域
电子元器件与电路板的多通道自动化测试。
多路信号切换与扫描测量系统搭建。
差分信号测量与低电平微弱信号采集。
半导体器件参数测试与老化筛选。
传感器多通道校准与数据采集。
自动测试设备（ATE）系统中的信号路由。
实验室科研测试中的多路复用开关应用。
生产线上的批量产品功能验证与质量检测。
结尾
总而言之，TEKTRONIX 7035-172-04A 继电器开关卡通道多、切换快、信号保真度高，是电子元器件及电路自动化测试系统中的标准多路切换组件
TEKTRONIX 7035-172-04A 继电器开关卡 英文介绍
TEKTRONIX 7035-172-04A is a high-density multiplexed relay switch card, compatible with 7001/7002 switch hosts, used for multi-channel signal switching testing, with stable switching and high channel density. The following are the core features and application areas of this model:
Product Features
Equipped with 9 independent 1 × 4 multi-channel switching channels, it can switch up to 18 input signals.
Adopting double blade A-type contacts, synchronously switching high and low signals, and adapting to differential signal measurement.
Single channel supports 60VDC/30V AC signals, with a switching current of 1A and a load of 30VA.
The channel leakage current is below 100pA, and there is no significant interference offset in weak signal testing.
The relay has a closing time of only 3ms and a switching speed of 100 channels per second.
Equipped with standard 96 pin DIN male connectors, batch wiring is convenient and neat.
High inter channel isolation and low channel capacitance reduce signal crosstalk distortion.
Built in industrial electromagnetic relay, with long contact life and high reliability in long-term testing.
Application Domain
Multi channel automated testing of electronic components and circuit boards.
Construction of a multi-channel signal switching and scanning measurement system.
Differential signal measurement and low-level weak signal acquisition.
Semiconductor device parameter testing and aging screening.
Multi channel calibration and data acquisition of sensors.
Signal routing in Automatic Test Equipment (ATE) systems.
Application of multiplex switches in laboratory scientific research testing.
Batch product functional verification and quality testing on the production line.
ending
In summary, the TEKTRONIX 7035-172-04A relay switch card has multiple channels, fast switching, and high signal fidelity, making it a standard multi way switching component in electronic components and circuit automation testing systems
TEKTRONIX 7035-172-04A 继电器开关卡 产品图片
