JAI GO-5100C-PGE 扫描相机 PDF资料
1.产 品 资 料 介 绍：
JAI GO-5100C-PGE 是一款500万像素级工业面阵扫描相机，采用Sony IMX250全局快门CMOS传感器，兼具高画质与紧凑设计。以下是该型号的核心特点与应用领域：
产品特点
搭载Sony IMX250 2/3" 全局快门CMOS，分辨率2464 × 2056。
全分辨率帧率约22帧/秒，输出8/10/12-bit彩色图像数据。
机身尺寸29×29×41.5mm，重量仅46克，适合紧凑空间安装。
支持GigE Vision标准接口，兼容PoE供电，单线缆完成传输与供电。
工业级坚固设计，抗冲击80G、抗振动10G，可靠性高。
低噪声成像，动态范围超过72dB，适应明暗差异大的场景。
支持ROI区域裁剪及多区域读出，灵活适应不同视野需求。
内置自动白平衡、像素校正、阴影补偿等图像优化功能。
应用领域
工业自动化产线上的外观与缺陷检测。
电子制造中的元器件精密定位与尺寸测量。
汽车零部件装配质量检查与表面瑕疵识别。
条码读取、字符识别与追溯系统。
药品包装完整性检测与标签校对。
机器人抓取定位与视觉引导。
户外安防监控及交通违章抓拍。
生物医学实验及科研成像。
结尾
总之，JAI GO-5100C-PGE 凭借其出色的成像质量、小巧坚固的机身和灵活的接口，为各类机器视觉与检测应用提供了可靠且高效的解决方案
JAI GO-5100C-PGE is a 5-megapixel industrial area scan camera that features a Sony IMX250 global shutter CMOS sensor, combining high image quality with a compact design. The following are the core features and application areas of this model:
Product Features
Equipped with Sony IMX250 2/3 "global shutter CMOS, with a resolution of 2464 × 2056.
The full resolution frame rate is about 22 frames per second, and it outputs 8/10/12 bit color image data.
The body size is 29 × 29 × 41.5mm, weighing only 46 grams, suitable for compact space installation.
Support GigE Vision standard interface, compatible with PoE power supply, single cable for transmission and power supply.
Industrial grade sturdy design, shock resistance of 80G, vibration resistance of 10G, high reliability.
Low noise imaging with a dynamic range exceeding 72dB, suitable for scenes with large differences in brightness and darkness.
Support ROI region cropping and multi region readout, flexibly adapting to different field of view requirements.
Built in image optimization functions such as automatic white balance, pixel correction, and shadow compensation.
Application Domain
Appearance and defect detection on industrial automation production lines.
Precision positioning and dimensional measurement of electronic components in electronic manufacturing.
Quality inspection and surface defect identification of automotive parts assembly.
Barcode reading, character recognition, and traceability system.
Integrity testing and label verification of drug packaging.
Robot grasping positioning and visual guidance.
Outdoor security monitoring and traffic violation capture.
Biomedical experiments and scientific imaging.
ending
In summary, JAI GO-5100C-PGE provides reliable and efficient solutions for various machine vision and inspection applications with its excellent imaging quality, compact and sturdy body, and flexible interfaces
