AMAT 0190-29030 远程设备网络扫描仪 PDF资料

1.产 品 资 料 介 绍：

AMAT 0190-29030 远程设备网络扫描仪简介

AMAT 0190-29030 是应用材料公司半导体设备中使用的远程 DeviceNet 网络扫描仪模块，硬件实质为 Brad Communications SST-EDN-1 型号，在设备控制系统中承担 EtherNet/IP 与 DeviceNet 现场总线之间的通信桥接职能。

产品特点（8条）

1. 实质为 Brad SST-EDN-1，由应用材料配套使用

2. EtherNet/IP 到 DeviceNet 的协议转换网关

3. 将以太网指令桥接至 DeviceNet 设备网络

4. 适配 CompactPCI 或 VME 等工业控制机箱

5. 连接控制器与远程 I/O、传感器、执行器

6. 存在 Rev 01/03/04/05 等多个硬件版本

7. 关联备件编号 0190-29030、0190-60305、0190-60306

8. 符合半导体设备规格要求

主要应用领域（8条）

1. 半导体刻蚀设备，作为控制器与腔室设备的通信接口

2. 化学气相沉积系统，连接气体流量控制器与压力传感器

3. 物理气相沉积设备，协调靶材电源与冷却系统通信

4. 晶圆搬运模块，管理机械手臂与真空阀门信号

5. 设备控制柜集成，作为 VME/CompactPCI 架构的 I/O 扫描节点

6. 远程 I/O 与联锁系统，实现安全信号可靠传输

7. 产线设备维保，替换老旧或故障模块

8. 设备升级改造，作为 EtherNet/IP 接入 DeviceNet 的网关

综上所述，AMAT 0190-29030 远程设备网络扫描仪凭借协议转换和网络桥接能力，在半导体工艺设备中承担着连接工业以太网与 DeviceNet 现场设备的关键通信职能。

AMAT 0190-29030 远程设备网络扫描仪  英文介绍

Introduction to AMAT 0190-29030 Remote Device Network Scanner

AMAT 0190-29030 is a remote DeviceNet network scanner module used in semiconductor equipment at Applied Materials. The hardware is essentially the Brad Communications SST-EDN-1 model, which serves as a communication bridge between EtherNet/IP and DeviceNet fieldbus in the device control system.

Product features (8 items)

Essentially Brad SST-EDN-1, used in conjunction with the application material

Protocol Conversion Gateway from EtherNet/IP to DeviceNet

Bridge Ethernet commands to the DeviceNet device network

Compatible with industrial control chassis such as CompactPCI or VME

Connect the controller to remote I/O, sensors, and actuators

There are multiple hardware versions such as Rev 01/03/04/05

Associated spare part numbers 0190-29030, 0190-60305, 0190-60306

Meets the specifications of semiconductor equipment

Main application areas (8 items)

Semiconductor etching equipment, serving as a communication interface between the controller and chamber equipment

Chemical vapor deposition system, connecting gas flow controller and pressure sensor

Physical vapor deposition equipment, coordinating communication between target material power supply and cooling system

Wafer handling module, managing signals from robotic arms and vacuum valves

Integration of equipment control cabinet as an I/O scanning node for VME/CompactPCI architecture

Remote I/O and interlocking system to achieve reliable transmission of safety signals

Maintenance of production line equipment, replacement of old or faulty modules

Equipment upgrade and transformation, serving as a gateway for EtherNet/IP access to DeviceNet

In summary, the AMAT 0190-29030 remote device network scanner, with its protocol conversion and network bridging capabilities, plays a critical communication role in connecting industrial Ethernet and DeviceNet field devices in semiconductor process equipment.

AMAT 0190-29030 远程设备网络扫描仪 产品图片

3.其他产品

IC698CPE030CPU控制器模块
IC693CPU374可编程控制器
DSQC658 3HAC025779-001机器人通讯板卡

4.其它产品推荐

CP238TA1 Expansion CARDS
KOKUSAI CXP-544A KOMS-A2 Main control circuit board
EATON DPM-MC2 Main communication module

本篇文章出自瑞昌明盛自动化设备有限公司官网，转载请附上此链接:https://www.jiangxidcs.com/

型号：AMAT 0190-29030 远程设备网络扫描仪

质保：一年

成色：全新/二手
