B&R 5PC720.1214-00 触摸屏面板 PDF资料
1.产 品 资 料 介 绍：
B&R 5PC720.1214-00 触摸屏面板
产品特点
属于B&R Panel PC 720系列，集显示与控制于一体。
配备12.1英寸SVGA彩色TFT显示屏，分辨率800×600。
采用电阻式触摸屏，支持戴手套操作。
前面板防护等级IP65，防尘防水溅。
工作温度范围0℃至+50℃。
支持24V DC供电。
配备2个10/100 Mbps以太网接口。
配备2个RS232串行通信接口。
配备3个USB 2.0接口。
配备PS/2接口，可连接键盘鼠标。
应用领域
工业自动化生产线的人机交互与设备监控。
过程控制DCS系统中的操作员站与数据显示。
包装机械中的参数设定与运行状态显示。
食品饮料行业的设备控制与生产数据记录。
水处理及环保监控系统的现场操作界面。
工厂设备维护与诊断系统的本地显示终端。
总结
该面板是B&R Panel PC 720系列的经典工业触摸屏，以12.1英寸显示、电阻触控及丰富接口为核心优势，适用于各类工业自动化人机交互场景。该型号属于早期产品线，目前在役设备主要用于存量系统的维护与升级。
B&R 5PC720.1214-00 Touch Screen Panel
Product Features
Belonging to the B&R Panel PC 720 series, it integrates display and control.
Equipped with a 12.1-inch SVGA color TFT display screen with a resolution of 800 × 600.
Adopting a resistive touch screen, it supports glove wearing operation.
The front panel has a protection level of IP65 and is dustproof, waterproof, and splash proof.
The working temperature range is from 0 ℃ to+50 ℃.
Supports 24V DC power supply.
Equipped with 2 10/100 Mbps Ethernet interfaces.
Equipped with 2 RS232 serial communication interfaces.
Equipped with 3 USB 2.0 interfaces.
Equipped with PS/2 interface, can connect keyboard and mouse.
Application Domain
Human computer interaction and equipment monitoring in industrial automation production lines.
Operator station and data display in process control DCS system.
Parameter setting and operation status display in packaging machinery.
Equipment control and production data recording in the food and beverage industry.
On site operation interface for water treatment and environmental monitoring system.
Local display terminal for factory equipment maintenance and diagnostic system.
summary
This panel is a classic industrial touch screen of the B&R Panel PC 720 series, with 12.1-inch display, resistive touch, and rich interfaces as its core advantages, suitable for various industrial automation human-machine interaction scenarios. This model belongs to the early product line, and currently in service equipment is mainly used for maintenance and upgrading of existing systems.
