B&R 80SD100XD.C0XX -01 步进驱动器 PDF资料
1.产 品 资 料 介 绍：
B&R 80SD100XD.C0XX-01 步进驱动器
产品特点
属于B&R ACOPOSmicro系列，可同时控制2台两相双极步进电机。
每步最大细分256微步，实现高精度定位。
每轴持续电流10A，峰值电流15A。
电源电压24至64V DC，允许±25%波动。
通过X2X Link总线通信，最小循环时间250μs。
支持自动电机识别功能。
保持电流、升压电流和持续电流可独立设定。
配备2路数字输入、1路数字输出及电机抱闸控制。
具备过载、短路和反接保护功能。
工作环境温度0至45℃，防护等级IP20。
应用领域
包装机械中的送料、定位和切割控制。
电子装配设备中的精密定位与对位。
3D打印机及CNC小型机床的轴驱动。
贴标机、灌装机等自动化生产线的步进控制。
实验室自动化设备中的样品处理与移液控制。
纺织机械中的张力控制与送纱系统。
总结
80SD100XD.C0XX-01是B&R ACOPOSmicro系列的高性能双轴步进驱动器，以高电流输出、256微步细分及自动电机识别为核心优势，适用于包装、电子制造、实验室自动化等需要多轴步进控制的应用场景。
B&R 80SD100XD.C0XX -01 步进驱动器 英文介绍
B&R 80SD100XD. C0XX-01 Stepper Driver
Product Features
Belonging to the B&R ACOPOSmitro series, it can simultaneously control 2 two-phase bipolar stepper motors.
Each step can be subdivided into a maximum of 256 micro steps to achieve high-precision positioning.
Each axis has a continuous current of 10A and a peak current of 15A.
The power supply voltage is between 24 and 64V DC, with a tolerance of ± 25% fluctuation.
Through X2X Link bus communication, the minimum cycle time is 250 μ s.
Support automatic motor recognition function.
The holding current, boost current, and sustained current can be independently set.
Equipped with 2 digital inputs, 1 digital output, and motor brake control.
Equipped with overload, short circuit, and reverse connection protection functions.
The working environment temperature ranges from 0 to 45 ℃, with a protection level of IP20.
Application Domain
Feeding, positioning, and cutting control in packaging machinery.
Precise positioning and alignment in electronic assembly equipment.
Axis drive for 3D printers and CNC small machine tools.
Step control of automated production lines such as labeling machines and filling machines.
Sample processing and pipetting control in laboratory automation equipment.
Tension control and yarn feeding system in textile machinery.
summary
80SD100XD. C0XX-01 is a high-performance dual axis stepper driver from the B&R ACOPOSmitcro series, featuring high current output, 256 micro step subdivision, and automatic motor recognition as its core advantages. It is suitable for applications such as packaging, electronic manufacturing, and laboratory automation that require multi axis stepper control.
B&R 80SD100XD.C0XX -01 步进驱动器 产品图片
