CBO22-P 3BDH000736R1二进制输出模块 PDF资料
1.产 品 资 料 介 绍：
CBO22-P 3BDH000736R1 二进制输出模块
产品特点
属于ABB Symphony Plus DCS系统的二进制输出模块。
提供32路独立数字量输出通道，支持同时控制多个现场设备。
采用电子固态输出（晶体管）技术，无机械触点磨损，开关寿命超1亿次。
输出支持内部（55/110/220mA）和外部（250/500/1000mA）双电流等级配置，灵活适配不同负载。
支持阻性、感性和容性等多种负载类型。
通道切换速度小于1ms，适用于高频脉冲及PWM控制场景。
输出通道支持分组配置，具备独立限流和诊断功能。
紧凑型设计，宽度仅45mm，节省机柜安装空间。
模块净重0.7kg，外形尺寸45×340×204mm。
工作温度范围-20℃至+60℃，适应恶劣工业环境。
应用领域
化工反应釜、精馏塔等场景中控制气动和液压电磁阀。
泵站、输送系统中控制电机接触器及变频器启停信号。
控制控制室及现场指示灯、塔灯和声光报警装置。
包装生产线中控制气缸、换向挡板和产品剔除装置。
楼宇自动化中管理暖通空调执行器、照明接触器和门禁锁。
火电、水处理等过程控制DCS系统中的设备驱动与安全联锁。
总结
CBO22-P是ABB Symphony Plus系统的高密度数字输出模块，核心优势在于32通道固态输出、双电流等级灵活配置及快速开关响应，广泛适用于过程工业、离散制造和楼宇自动化等领域中对电磁阀、接触器和指示设备的高可靠控制。
CBO22-P 3BDH000736R1二进制输出模块 英文介绍
CBO22-P 3BDH000736R1 Binary Output Module
Product Features
Binary output module belonging to ABB Symphony Plus DCS system.
Provide 32 independent digital output channels, supporting simultaneous control of multiple field devices.
Adopting electronic solid-state output (transistor) technology, there is no mechanical contact wear, and the switch life exceeds 100 million times.
Output supports dual current level configurations for internal (55/110/220mA) and external (250/500/1000mA), flexibly adapting to different loads.
Supports multiple load types such as resistive, inductive, and capacitive.
The channel switching speed is less than 1ms, suitable for high-frequency pulse and PWM control scenarios.
The output channel supports group configuration and has independent current limiting and diagnostic functions.
Compact design with a width of only 45mm, saving cabinet installation space.
The net weight of the module is 0.7kg, and the external dimensions are 45 × 340 × 204mm.
The working temperature range is -20 ℃ to+60 ℃, suitable for harsh industrial environments.
Application Domain
Control pneumatic and hydraulic solenoid valves in scenarios such as chemical reaction vessels and distillation towers.
Control motor contactors and frequency converter start stop signals in pump stations and conveying systems.
Control room and on-site indicator lights, tower lights, and sound and light alarm devices.
Control cylinders, reversing baffles, and product removal devices in the packaging production line.
Manage HVAC actuators, lighting contactors, and access locks in building automation.
Equipment driving and safety interlocking in DCS systems for process control of thermal power and water treatment.
summary
CBO22-P is a high-density digital output module of ABB Symphony Plus system, with the core advantages of 32 channel solid-state output, flexible configuration of dual current levels, and fast switch response. It is widely used for high reliability control of solenoid valves, contactors, and indicator devices in process industries, discrete manufacturing, and building automation.
CBO22-P 3BDH000736R1二进制输出模块 产品图片
