HURCO 415-0601总线输入/输出模块 PDF资料
HURCO 415-0601 总线输入/输出模块的特点和应用领域
产品特点：
属于 HURCO（赫克）数控机床的 CANBUS DC I/O 节点电路板。
完整型号为 415-0601-903，常见版本为 Rev F、Rev J。
采用 CAN 总线通信，实现分布式 I/O 信号交互。
负责机床开关输入与输出信号的采集和驱动。
采用 DC 24V 供电，兼容机床控制柜电源电路。
板载总线接口端子，支持多节点联网通信。
集成信号隔离元件，降低现场干扰影响。
板载状态指示灯，可直观查看通道运行状态。
具备通道过流保护，降低过载损坏风险。
采用插槽式安装结构，便于柜内拆装。
应用领域：
主要用于 HURCO 品牌 CNC 机床的控制系统。
兼容 HURCO BMC 40、BMC30HT 等加工中心机型。
用于数控机床的 I/O 扩展与设备信号转接。
与系统中其他 Autocon 节点模块协同工作。
在 CAN 总线通信异常或 I/O 通道故障时是排查环节之一。
综上，HURCO 415-0601 是赫克数控机床中的 CANBUS DC I/O 节点电路板，主要承担分布式 I/O 信号采集与驱动任务，应用于 BMC 系列加工中心的电气控制环节
Characteristics and application areas of HURCO 415-0601 bus input/output module
Product Features:
The CANBUS DC I/O node circuit board belonging to HURCO CNC machine tools.
The complete model is 415-0601-903, and the common versions are Rev F and Rev J.
Using CAN bus communication to achieve distributed I/O signal interaction.
Responsible for collecting and driving input and output signals of machine tool switches.
Adopting DC 24V power supply, compatible with the power circuit of the machine tool control cabinet.
Onboard bus interface terminal, supporting multi node networking communication.
Integrate signal isolation components to reduce the impact of on-site interference.
Onboard status indicator light, allowing for intuitive viewing of channel operation status.
Equipped with channel overcurrent protection to reduce the risk of overload damage.
Adopting a slot type installation structure, it is easy to disassemble and assemble inside the cabinet.
Application fields:
Mainly used for the control system of HURCO brand CNC machine tools.
Compatible with HURCO BMC 40, BMC30HT and other machining center models.
Used for I/O expansion and equipment signal conversion in CNC machine tools.
Collaborate with other Autocon node modules in the system.
One of the troubleshooting steps is when CAN bus communication is abnormal or I/O channel faults occur.
In summary, HURCO 415-0601 is a CANBUS DC I/O node circuit board in Heck CNC machine tools, mainly responsible for distributed I/O signal acquisition and driving tasks, applied in the electrical control link of BMC series machining centers
