BYSTRONIC E0714-5-B接口模块  PDF资料

1.产 品 资 料 介 绍：

BYSTRONIC E0714-5-B 是百超激光切割机控制系统里的一块接口模块板卡，关联编号 EDV NR 4630410，部分资料里叫 IMPGEN Board。

产品特点

1 百超激光切割机控制系统的板卡类备件，负责接口或扩展 I/O 功能
2 常跟 4630410 这个 EDV NR 编号关联，对编号比只对型号更准
3 在 ByStar Fiber、ByCut Smart 等系列设备上有应用
4 有维修商提供元件级修复服务
5 公开电气参数极少，靠原板标识匹配

产品参数

1 品牌 BYSTRONIC，型号 E0714-5-B
2 关联编号 EDV NR 4630410
3 类型为接口模块或控制板卡
4 供电涉及 24V DC 总线体系
5 详细参数未公开，需参考原板或原厂手册

应用领域

1 百超 ByStar Fiber 系列激光切割机
2 百超 ByCut Smart 系列激光切割机
3 百超激光切割机的接口信号处理环节
4 专业百超维修商的备件范围
5 老旧百超系统的板卡替换

总结

BYSTRONIC E0714-5-B 就是百超激光切割机控制系统里的一块接口板卡，关联编号 4630410。

BYSTRONIC E0714-5-B接口模块   英文介绍

BYSTRONIC E0714-5-B is an interface module board in the control system of the Baichao laser cutting machine, with the associated number EDV NR 4630410, and is referred to as IMPGEN Board in some materials.

Product Features

Spare board components for the control system of the 100+laser cutting machine, responsible for interfaces or expanding I/O functions

2 is often associated with the EDV NR number 4630410, which is more accurate for the number than only for the model

3 has applications on ByStar Fiber, ByCut Smart and other series of devices

4 repair shops provide component level repair services

5. There are very few publicly available electrical parameters, which are matched by the original board identification

Product Specifications

Brand BYSTRONIC, Model E0714-5-B

2 Association Number EDV NR 4630410

3 types are interface modules or control boards

4. Power supply involves a 24V DC bus system

5 detailed parameters not disclosed, please refer to the original board or factory manual

Application Areas

100 Super ByStar Fiber Series Laser Cutting Machine

200 Super ByCut Smart Series Laser Cutting Machine

Interface signal processing link of 300 super laser cutting machine

Scope of spare parts for 4 professional over 100 repair shops

5. Replacement of old and outdated boards in the Baichao system

Summary

BYSTRONIC E0714-5-B is an interface board in the control system of the Baichao laser cutting machine, with association number 4630410.

BYSTRONIC E0714-5-B接口模块  产品图片
