OMRON S82J-15024C-601电源模块  PDF资料

1.产 品 资 料 介 绍：

OMRON S82J-15024C-601 是欧姆龙 S82J 系列的一款 150W 开关电源，24V 输出，属于欧姆龙经典的工业电源产品线。

产品特点

1 属于 S82J 系列 150W 机型，24V 输出 6.5A，中功率档
2 型号后缀区分安装形式，C 通常对应带盖或特定接口版本
3 支持 DIN 导轨安装，配 S82Y 系列安装底座，方便集成到控制柜
4 具备过载保护和过电压保护，24V 机型过载保护在 105% 到 160% 额定电流范围动作
5 输出保持时间约 20ms 以上，掉电时能给负载留出缓冲

产品参数

1 容量 150W，输出 24V DC，额定电流 6.5A
2 输入电压 AC100 到 240V 自由输入，50/60Hz
3 电压调整范围 -10% 到 +15%，可通过 VADJ 电位器微调
4 效率典型值 90%，24V 机型在 230V AC 输入时
5 工作环境温度范围较宽，工业现场适用

应用领域

1 工业自动化控制柜内，给 PLC、传感器和继电器供电
2 欧姆龙 CP1 系列等 PLC 的 I/O 电源和通信电源
3 机床和产线设备的 24V 直流控制回路
4 需要 DIN 导轨安装、空间紧凑的电气柜
5 S82J 系列电源的维修替换

总结

OMRON S82J-15024C-601 就是欧姆龙 S82J 系列里的一款 150W 24V 工业开关电源，6.5A 输出，带保护和电压微调功能，主要用在自动化控制柜里给 PLC 和传感器供电。

OMRON S82J-15024C-601电源模块   英文介绍

OMRON M-2J-15024C-601 is a 150W switching power supply in the Omron M-2J series, with a 24V output, belonging to Omron's classic industrial power supply product line.

Product Features

1 belongs to the S82J series 150W model, 24V output 6.5A, medium power level

Two types of suffixes distinguish installation forms, with C usually corresponding to covered or specific interface versions

3 supports DIN rail installation and comes with an S82Y series mounting base, making it easy to integrate into the control cabinet

Equipped with overload protection and overvoltage protection, the 24V model's overload protection operates within the rated current range of 105% to 160%

5 output holding time is about 20ms or more, which can leave a buffer for the load when power is lost

Product Specifications

1. Capacity 150W, output 24V DC, rated current 6.5A

2 Input Voltage AC100 to 240V Free Input, 50/60Hz

The voltage adjustment range is -10% to+15%, which can be fine tuned through the VADJ potentiometer

4. Typical efficiency value of 90%, 24V model at 230V AC input

The working environment has a wide temperature range and is suitable for industrial sites

Application Areas

Inside the industrial automation control cabinet, power is supplied to PLCs, sensors, and relays

I/O power supply and communication power supply for PLC such as Omron CP1 series

24V DC control circuit for machine tools and production line equipment

4. Electrical cabinets that require DIN rail installation and compact space

Repair and replacement of the 5 S82J series power supply

Summary

OMRON S82J-15024C-601 is a 150W 24V industrial switch power supply in the OMRON S82J series, with 6.5A output, protection and voltage fine-tuning functions. It is mainly used in automation control cabinets to supply power to PLCs and sensors.

OMRON S82J-15024C-601电源模块  产品图片
