DENSEI LAMBDA JWS150-24/A电源模块 PDF资料

1.产 品 资 料 介 绍：

先唠两句

DENSEI LAMBDA JWS150-24/A 是 TDK-Lambda 旗下 JWS 系列的一款封闭式工业开关电源，单路输出 24V。这型号已经停产了，市面上流通的基本是库存件或拆机件。

产品特点

1 宽范围交流输入，85 到 265V 都能接，全球电压通用
2 带功率因数校正和遥感功能，输出电压可以微调
3 自然空冷散热，没有风扇，靠对流冷却，适合安静环境
4 内置过流和过压保护，过流保护在 6.82A 左右动作
5 封闭式金属外壳，带盖板，防护性比开放式电源好

产品参数

1 输出 24V DC，最大电流 6.5A，最大功率 156W
2 输出可调范围 21.6 到 26.4V DC
3 效率典型值 80%，纹波噪声 150mV 峰峰值
4 外形尺寸 198 x 92 x 65mm，重量约 900g
5 工作温度 -10 到 +50°C，储存温度 -30 到 +85°C

应用领域

1 工业自动化和过程控制系统供电
2 测试测量仪器和传感仪表设备
3 诺信 MEGTEC 印刷设备等工业机械
4 医疗 X 光设备如 Discovery 系列的电源配套
5 老旧 JWS 系列电源的维修替换

总结

DENSEI LAMBDA JWS150-24/A 就是一块 24V 6.5A 的工业开关电源，宽压输入、自然散热、带保护功能，主要用在自动化和工业设备上。

DENSEI LAMBDA JWS150-24/A电源模块  英文介绍

Let's have a few words first

DENSEI LAMBDA JWS 150-24/A is a closed industrial switch power supply from TDK Lambda's JWS series, with a single output of 24V. This model has been discontinued and is mainly available in stock or disassembled parts on the market.

Product Features

1 wide range AC input, capable of connecting from 85 to 265V, globally applicable voltage

Equipped with power factor correction and remote sensing functions, the output voltage can be fine tuned

3. Natural air cooling without fans, relying on convection cooling, suitable for quiet environments

4 built-in overcurrent and overvoltage protection, overcurrent protection operates at around 6.82A

5 enclosed metal casing with cover plate, better protection than open power supply

Product Specifications

Output 24V DC, maximum current 6.5A, maximum power 156W

2 output adjustable range 21.6 to 26.4V DC

Typical efficiency value of 80%, ripple noise of 150mV peak to peak

4. Dimensions 198 x 92 x 65mm, weight approximately 900g

5 working temperature -10 to+50 ° C, storage temperature -30 to+85 ° C

Application Areas

1. Power supply for industrial automation and process control systems

2. Testing and measuring instruments and sensing equipment

3 Nuoxin MEGTEC printing equipment and other industrial machinery

4. Power supply matching for medical X-ray equipment such as Discovery series

Maintenance and replacement of 5 old JWS series power supplies

Summary

DENSEI LAMBDA JW150-24/A is an industrial switch power supply with 24V 6.5A, wide voltage input, natural heat dissipation, and protection function. It is mainly used in automation and industrial equipment.

DENSEI LAMBDA JWS150-24/A电源模块 产品图片
