REXROTH VT5041-25/1放大器 PDF资料

1.产 品 资 料 介 绍：

先唠两句

REXROTH VT5041-25/1 是力士乐的一款模拟放大器板卡，欧式插件卡格式，专门用来控制液压比例阀。这板子在工业液压系统里挺常见，现在属于老型号备件。

产品特点

1 欧式插件卡设计，直接插在标准卡架上用，集成方便
2 带差动放大器输入，信号处理精度和抗干扰能力不错
3 有可调斜坡时间，上升和下降可以分开调，优化阀芯动作
4 内置短路保护和电源极性反转保护，安全性有保障
5 前面板带LED指示灯，工作状态一目了然

产品参数

1 供电电压 24V DC，允许 +40% 到 -5% 波动
2 指令值输入为差动输入，范围 0 到 +10V、0 到 -10V 或 ±10V
3 最大输出电流 1.6A，能驱动大多数比例阀电磁铁
4 斜坡时间可调，范围 0.02 秒到 5 秒
5 工作温度 0 到 +50°C，存储温度 -20 到 +70°C

应用领域

1 控制比例压力阀，比如 DBE、DRE、ZDRE 这些系列
2 数控机床的液压系统比例控制
3 注塑机的压力和流量控制回路
4 自动化产线上的液压执行元件驱动
5 老旧液压设备的维修替换，属于停产但还在用的备件

总结

REXROTH VT5041-25/1 就是力士乐的一款老款模拟放大器卡，24V供电、最大输出1.6A、带可调斜坡，主要用来驱动比例压力阀

REXROTH VT5041-25/1放大器  英文介绍

Let's have a few words first

REXROTH VT5041-25/1 is an analog amplifier board from Rexroth, designed in European plug-in card format specifically for controlling hydraulic proportional valves. This board is quite common in industrial hydraulic systems and now belongs to the old model spare parts.

Product Features

1 European plug-in card design, directly plugged into a standard card holder for easy integration

2 with differential amplifier input, good signal processing accuracy and anti-interference ability

3. There is an adjustable ramp time, and the rise and fall can be adjusted separately to optimize the valve core action

4 built-in short-circuit protection and power polarity reversal protection, ensuring safety

5 front panel with LED indicator lights, the working status is clear at a glance

Product Specifications

1. Power supply voltage 24V DC, allowing+40% to -5% fluctuation

The instruction value input is a differential input with a range of 0 to+10V, 0 to -10V, or ± 10V

3 maximum output current of 1.6A, capable of driving most proportional valve electromagnets

4 slope time adjustable, ranging from 0.02 seconds to 5 seconds

5 working temperature: 0 to+50 ° C, storage temperature: -20 to+70 ° C

Application Areas

1. Control proportional pressure valves, such as DBE, DRE, ZDRE series

Proportional control of hydraulic system for CNC machine tools

Pressure and flow control circuit of injection molding machine

Hydraulic actuator drive on automated production line

The maintenance and replacement of 5 old hydraulic equipment are spare parts that have been discontinued but are still in use

Summary

REXROTH VT5041-25/1 is an old analog amplifier card from Rexroth, powered by 24V, with a maximum output of 1.6A and an adjustable ramp, mainly used to drive proportional pressure valves

REXROTH VT5041-25/1放大器 产品图片
