PARKER PM1200B电源模块 PDF资料

1.产 品 资 料 介 绍：

先唠两句

PARKER PM1200B 是派克旗下 Digiplan 系列的一款工业电源模块，专门给 CD 系列驱动器配套供电用的。这模块现在属于停产备件。

产品特点

1 专为 Parker CD 系列伺服驱动器设计的配套电源，系统匹配度高

2 机架式安装设计，方便集成到工业控制柜里

3 内置过压、过流和短路保护，安全性有保障

4 带冷却风扇，散热效率不错，能防止过热

5 宽输入电压范围，支持 100 到 240V 交流电

产品参数

1 输出为 20V 交流三相，这是给 CD 驱动器供电的核心规格

2 交流输入逻辑供电为 20V RMS 3A，电机供电最高 61V RMS 20A

3 直流输出方面，逻辑供电 +24V 2A，电机供电最高 +85V 15A

4 最大输出功率达到 1200 瓦，功率密度比较高

5 保险丝配置：逻辑供电 3.15A，功率泄放 2A 抗浪涌延时型

应用领域

1 配套 Parker CD20、CD25、CD30、CD35、CD40 等系列伺服驱动器使用

2 数控机床的驱动系统供电

3 自动化产线和机器人系统的电源部分

4 需要三相交流供电的工业控制场合

5 老旧 Parker 驱动系统的维修替换，属于停产但还得用的备件

总结

PARKER PM1200B 就是给派克 CD 系列驱动器配套的工业电源模块，输出 20V 三相交流，带 24V 和高压直流输出，主要用在数控机床和自动化产线上。

PARKER PM1200B电源模块  英文介绍

Let's have a few words first

PARKER PM1200B is an industrial power module from the Digiplan series under Parker, specifically designed to power CD series drives. This module is now a discontinued spare part.

Product Features

A matching power supply designed specifically for Parker CD series servo drives, with high system compatibility

2-rack installation design, easy to integrate into industrial control cabinets

3 built-in overvoltage, overcurrent, and short-circuit protection, ensuring safety

4 with cooling fan, good heat dissipation efficiency, can prevent overheating

5 wide input voltage range, supporting 100 to 240V AC power

Product Specifications

The output is 20V AC three-phase, which is the core specification for powering CD drives

2 AC input logic power supply is 20V RMS 3A, motor power supply is up to 61V RMS 20A

In terms of DC output, logic power supply+24V 2A, motor power supply up to+85V 15A

The maximum output power of 4 reaches 1200 watts, and the power density is relatively high

5 Fuse configuration: Logic power supply 3.15A, power release 2A, anti surge delay type

Application Areas

1. Used with Parker CD20, CD25, CD30, CD35, CD40 and other series servo drives

Power supply for the drive system of CNC machine tools

Power supply for automated production lines and robot systems

Industrial control applications that require three-phase AC power supply

The maintenance and replacement of the old Parker drive system is a spare part that has been discontinued but still needs to be used

Summary

PARKER PM1200B is an industrial power module designed to match Parker CD series drives. It outputs 20V three-phase AC with 24V and high-voltage DC outputs, and is mainly used in CNC machine tools and automation production lines.

PARKER PM1200B电源模块 产品图片
