PROFACE PFXGP4601TAD专业面部触摸屏 PDF资料
PROFACE PFXGP4601TAD 是普洛菲斯 GP4000 系列的一款 12.1 英寸人机界面触摸屏，DC 24V 供电，模拟电阻式触摸，带以太网和多种串口。
产品特点
12.1 英寸大屏
SVGA 分辨率 800x600，65,536 色显示，画面细腻，适合展示复杂图形和数据的场合。
接口齐全
带 RS232C、RS422/485 串口、以太网口、USB 和 SD 卡槽，能同时接多种设备。
防护等级高
前面板 IP65F，防尘防水溅，装在设备面板上能适应车间环境。
自然散热
无风扇设计，靠空气自然流通散热，减少故障点。
支持 GP-Pro EX 软件
用 Pro-face 的 GP-Pro EX 编程，画面制作方便。
产品参数
屏幕尺寸
12.1 英寸 TFT 彩色 LCD。
分辨率
800 x 600 像素 SVGA。
显示颜色
65,536 色。
触摸方式
模拟电阻式单点触摸。
供电
DC 24V，允许 19.2 到 28.8V 波动。
功耗
17W 以下。
接口
COM1 RS232C，COM2 RS422/485，以太网，USB Type A 和 mini B，SD 卡槽。
面板开孔
301.5 x 227.5 毫米。
工作温度
0 到 55 摄氏度。
应用领域
工厂自动化产线
产线控制面板，显示设备状态和参数，操作员通过触摸屏控制流程。
机械设备 OEM
包装机、机床等设备的配套人机界面，12.1 英寸大屏适合展示复杂画面。
过程监控
化工、水处理等过程控制系统的监控画面，多接口方便接入 PLC 和仪表。
老旧设备升级替换
GP-2600T 或 GP-3600T 等老机型升级替换，PFXGP4601TAD 尺寸和接口兼容性较好。
船舶与恶劣环境
带船舶认证版本，适用于有船级社要求的场合。
PFXGP4601TAD 就是 GP4000 系列 12.1 英寸的触摸屏，接口多、防护好，适合需要大屏显示和多种通信的工业场合。
PROFACE PFXGP4601TAD专业面部触摸屏 英文介绍
PROFACE PFXGP4601TAD is a 12.1-inch human-machine interface touch screen from the Proface GP4000 series, powered by DC 24V, simulating resistive touch, with Ethernet and multiple serial ports.
Product Features
12.1-inch large screen
SVGA resolution of 800x600, 65536 color display, delicate image, suitable for displaying complex graphics and data.
Complete interfaces
Equipped with RS232C, RS422/485 serial ports, Ethernet ports, USB and SD card slots, capable of connecting multiple devices simultaneously.
High protection level
The front panel is IP65F, dustproof and waterproof, and can adapt to the workshop environment when installed on the equipment panel.
Natural heat dissipation
Fanless design, relying on natural air circulation to dissipate heat and reduce failure points.
Support GP Pro EX software
Programming with Pro face GP Pro EX makes screen production convenient.
Product Specifications
screen size
12.1-inch TFT color LCD.
Resolution
800 x 600 pixel SVGA.
display color
65536 colors.
touch method
Simulate resistive single point touch.
power supply
DC 24V， Allow fluctuations from 19.2 to 28.8V.
power consumption
Below 17W.
interface
COM1 RS232C，COM2 RS422/485， Ethernet, USB Type A and mini B, SD card slot.
panel cutout
301.5 x 227.5 millimeters.
Operating Temperature
0 to 55 degrees Celsius.
Application Areas
Factory automation production line
The production line control panel displays equipment status and parameters, and the operator controls the process through a touch screen.
Mechanical equipment OEM
The supporting human-machine interface for packaging machines, machine tools, and other equipment, with a 12.1-inch large screen suitable for displaying complex images.
process monitoring
The monitoring screen of process control systems such as chemical engineering and water treatment, with multiple interfaces for easy access to PLC and instruments.
Upgrading and replacing old equipment
Upgrade and replace old models such as GP-2600T or GP-3600T, with good compatibility of PFXGP4601TAD size and interface.
Ships and harsh environments
Equipped with ship certification version, suitable for occasions with classification society requirements.
PFXGP4601TAD is a 12.1-inch touch screen from the GP4000 series, with multiple interfaces and good protection, suitable for industrial applications that require large screen displays and various communications.
PROFACE PFXGP4601TAD专业面部触摸屏 产品图片
