PRYOR MULTIDOT 3000 控制器面板 PDF资料
PRYOR MULTIDOT 3000 是英国 Pryor 公司的一款工业点阵打标机控制器，是 Marktronic Multidot 3000 打标系统的独立控制单元。
产品特点
独立控制器防冲击
控制器与打标头分开，电气部分免受打标过程的机械冲击。
大屏图形显示
嵌入式 LCD 屏幕，操作员不用接电脑就能控制整个打标过程。
集成键盘加 PS2 接口
控制器自带 QWERTY 键盘，还带 PS2 口可以外接键盘。
存储容量大
嵌入式 LCD 版可存 1350 个打标版面，Windows 版取决于硬盘容量。
接口丰富
两个 RS232 串口、数字 I/O，可选以太网 TCP/IP 或现场总线模块。
产品参数
适配机型
Marktronic Multidot 3000 点阵打标机。
通信接口
2 个 RS232 串口，数字 I/O，可选 USB、TCP/IP、Profibus、ProfiNet 等。
键盘配置
集成 QWERTY 薄膜键盘，带 PS2 外接键盘接口。
供电
220V / 50Hz。
重量
控制器约 10kg。
应用领域
工业零件标识
在金属零件上打标序列号、批次号和二维码。
航空航天追溯
配合 VeriSmart 验证系统，满足 IUID 和 Spec 2000 追溯要求。
汽车零部件打标
发动机、变速箱等关键件的永久性标识。
生产线集成
通过 RS232 或现场总线接入自动化产线，在线打标。
老旧设备维护替换
已有 Multidot 3000 系统的，控制器故障找同型号替换。
MULTIDOT 3000 控制器就是 PRYOR 点阵打标机的独立控制单元，负责界面操作和通信。选型时注意确认串口和总线配置跟现有系统匹配。
PRYOR MULTIDOT 3000 控制器面板 英文介绍
PRYOR MULTIDOT 3000 is an industrial dot matrix marking machine controller from Pryor, UK. It is an independent control unit of the Marktronic Multidot 3000 marking system.
Product Features
Independent controller anti impact
The controller is separated from the marking head, and the electrical part is protected from mechanical impact during the marking process.
Large screen graphic display
Embedded LCD screen allows operators to control the entire marking process without connecting to a computer.
Integrated keyboard with PS2 interface
The controller comes with a QWERTY keyboard and a PS2 port for external keyboard connection.
Large storage capacity
The embedded LCD version can store 1350 label layouts, while the Windows version depends on the hard drive capacity.
Rich interface
Two RS232 serial ports, digital I/O, optional Ethernet TCP/IP or fieldbus module.
Product Specifications
Compatible Models
Marktronic Multidot 3000 dot matrix marking machine.
Communication interface
2 RS232 serial ports, digital I/O, optional USB, TCP/IP, Profibus, ProfiNet, etc.
Keyboard configuration
Integrated QWERTY membrane keyboard with PS2 external keyboard interface.
power supply
220V / 50Hz。
weight
The controller weighs approximately 10kg.
Application Areas
Industrial parts identification
Mark the serial number, batch number, and QR code on metal parts.
Aerospace traceability
Cooperate with VeriSmart verification system to meet IUID and Spec 2000 traceability requirements.
Marking of automotive parts
Permanent identification of key components such as engines and transmissions.
Production line integration
Connect to the automated production line through RS232 or fieldbus for online marking.
Maintenance and replacement of old equipment
If there is already a Multidot 3000 system, replace the faulty controller with the same model.
The MULTIDOT 3000 controller is an independent control unit of the PRYOR dot matrix marking machine, responsible for interface operation and communication. When selecting, pay attention to confirming that the serial port and bus configurations match the existing system.
PRYOR MULTIDOT 3000 控制器面板 产品图片
