SEW MM07C-503-00逆变器 PDF资料
SEW MM07C-503-00 是 SEW MOVIMOT 系列的一款变频器模块，适配 0.75kW 电机，装在减速电机上做分布式驱动。
产品特点
分布式安装
变频器直接集成在电机上，不用装在控制柜里，省去长电缆和柜内空间。
0.75kW 功率
适配 0.75kW 电机，输出视在功率 1.8 kVA，额定输出电流 2.5A。
三相 380 到 500V 供电
宽电压输入，50/60Hz 电网都能用。
输出频率 2 到 100Hz
分辨率 0.01Hz，PWM 频率 4/8/16kHz 可调。
IP65 防护
防尘防水溅，适合直接装在设备现场。
产品参数
适配电机
0.75kW。
输入电压
三相 380 到 500V AC。
额定输入电流
1.9A。
额定输出电流
2.5A。
输出频率
2 到 100Hz。
防护等级
IP65。
零件号
8241171。
应用领域
分布式输送系统
输送线上用 MOVIMOT 减速电机，变频器直接装在电机上，省去集中控制柜。
物流分拣设备
分拣机、辊道输送机的驱动控制。
汽车生产线
汽车厂输送线和工位驱动，MOVIMOT 是常用方案。
仓储自动化
立体库、堆垛机的行走和提升驱动。
老旧 MOVIMOT 系统维护替换
变频器模块坏了找 MM07C-503-00 替换。
MM07C-503-00 就是 SEW MOVIMOT 分布式驱动里的 0.75kW 变频器模块，装在电机上而不是柜子里。选型时注意它是 MOVIMOT 系统的组成部分，得配合对应的减速电机用。
SEW MM07C-503-00逆变器 英文介绍
SEW MM07C-503-00 is a frequency converter module in the SEW MOVIMOT series, suitable for 0.75kW motors and installed on a reduction motor for distributed drive.
Product Features
distributed installation
The frequency converter is directly integrated into the motor, without the need to be installed in the control cabinet, saving long cables and cabinet space.
0.75kW power
Suitable for 0.75kW motor, output apparent power of 1.8 kVA, rated output current of 2.5A.
Three phase 380 to 500V power supply
Wide voltage input, compatible with both 50/60Hz power grids.
Output frequency 2 to 100Hz
Resolution of 0.01Hz, adjustable PWM frequency of 4/8/16kHz.
IP65 protection
Dustproof and waterproof, suitable for direct installation on the equipment site.
Product Specifications
Adapted motor
0.75kW。
input voltage
Three phase 380 to 500V AC.
Rated input current
1.9A。
Rated output current
2.5A。
output frequency
2 to 100Hz.
Protection level
IP65。
Part Number
8241171.
Application Areas
Distributed Conveyor System
MOVIMOT reduction motor is used on the conveyor line, and the frequency converter is directly installed on the motor, eliminating the need for a centralized control cabinet.
Logistics sorting equipment
Drive control of sorting machines and roller conveyors.
Automobile production line
MOVIMOT is a commonly used solution for driving conveyor lines and workstations in automobile factories.
Warehouse Automation
The walking and lifting drive of the three-dimensional warehouse and stacker crane.
Maintenance and replacement of old MOVIMOT system
Replace the frequency converter module with MM07C-503-00 if it is damaged.
MM07C-503-00 is the 0.75kW frequency converter module in SEW MOVIMOT distributed drive, installed on the motor instead of in the cabinet. When selecting, please note that it is an integral part of the MOVIMOT system and must be used in conjunction with the corresponding reduction motor.
SEW MM07C-503-00逆变器 产品图片
