MITSUBISHI FX3S-14MR/ES可编程控制器 PDF资料
MITSUBISHI FX3S-14MR/ES 是三菱 FX3S 系列的一款基础型可编程控制器，8 点输入加 6 点继电器输出，共 14 点 I/O。它是 FX1S 的升级替代型号，主打小规模控制和免维护。
产品特点
免维护设计
程序存在 EEPROM 里，不需要电池，掉电不丢程序，装上去基本不用管。
继电器输出
输出是继电器常开触点，最大 2A，交直流都能带，通用性好。
内置 USB 和 RS-422
自带 USB 编程口和 RS-422 串口，不用额外买通信板就能连电脑或触摸屏。
运算速度快
基本指令 0.21 微秒，比老款 FX1S 快不少，程序容量 4000 步。
可加扩展板
本体不能加扩展模块，但可以通过功能扩展板增加模拟量或通信功能。
产品参数
I/O 点数
输入 8 点，输出 6 点，共 14 点，不可扩展。
输出类型
继电器输出，2A / 240V AC 或 30V DC。
供电电压
100 到 240V AC。
程序容量
4000 步 EEPROM。
通信接口
USB 1 个，RS-422 1 个。
尺寸重量
宽 60 x 高 90 x 深 49 毫米，约 0.3 公斤。
产品状态
已停产，最后购买约 2027 年 1 月，维修支持到 2033 年。
应用领域
小规模设备控制
十几个点的简单设备，比如小型包装机、单机自动化装置。
替代老款 FX1S
安装尺寸跟 FX1S 一样，老设备坏了直接换，接线和程序基本不用大改。
维修不便的场合
免电池设计，适合装在不好经常打开检查的柜子里。
简单温度或流量控制
配上模拟量扩展板，可以做小型加热或冷却系统的闭环控制。
老旧设备延寿替换
已经在跑 FX1S 或 FX3S 的设备，控制器坏了找它替换就行。
FX3S-14MR/ES 就是给十几个点的小设备用的基础 PLC，免维护、带 USB、能加扩展板。
MITSUBISHI FX3S-14MR/ES可编程控制器 英文介绍
MITSUBISHI FX3S-14MR/ES is a basic programmable controller of Mitsubishi FX3S series, with 8-point input and 6-point relay output, totaling 14 I/O. It is an upgraded replacement model for FX1S, featuring small-scale control and maintenance free.
Product Features
Maintenance-free design
The program is stored in EEPROM, does not require a battery, does not lose the program in case of power failure, and can be installed without much care.
relay output
The output is a relay normally open contact, with a maximum of 2A, capable of carrying both AC and DC, and has good versatility.
Built in USB and RS-422
Equipped with a USB programming port and RS-422 serial port, it can be connected to a computer or touch screen without the need to purchase an additional communication board.
Fast computing speed
The basic instruction is 0.21 microseconds, which is much faster than the old FX1S and has a program capacity of 4000 steps.
Can add expansion board
The ontology cannot add expansion modules, but analog or communication functions can be added through the function expansion board.
Product Specifications
I/O point count
Input 8 points, output 6 points, a total of 14 points, non expandable.
output type
Relay output, 2A/240V AC or 30V DC.
power supply voltage
100 to 240V AC.
Program capacity
4000 step EEPROM.
Communication interface
1 USB and 1 RS-422.
Dimensions and Weight
Width 60 x height 90 x depth 49 millimeters, approximately 0.3 kilograms.
Product Status
Discontinued production, last purchased around January 2027, with maintenance support until 2033.
Application Areas
Small scale equipment control
Simple equipment with over ten points, such as small packaging machines and single machine automation devices.
Replace the old FX1S model
The installation size is the same as FX1S. If the old equipment breaks down, it can be replaced directly, and there is basically no need to make major changes to the wiring and program.
In situations where maintenance is inconvenient
Battery free design, suitable for installation in cabinets that are not easy to open and inspect frequently.
Simple temperature or flow control
Equipped with an analog expansion board, it can be used for closed-loop control of small heating or cooling systems.
Extended lifespan replacement of old equipment
The device is already running FX1S or FX3S. If the controller is broken, just replace it.
FX3S-14MR/ES is a basic PLC designed for small devices with over a dozen points, which is maintenance free, comes with USB, and can be equipped with an expansion board.
MITSUBISHI FX3S-14MR/ES可编程控制器 产品图片
