MITSUBISHI FR-A024-0.75K驱动变频器 PDF资料
MITSUBISHI FR-A024-0.75K 是三菱 FREQROL-A024 系列的一款经典小型变频器，额定功率 0.75kW，也就是 1HP，采用 V/F 控制方式，主打紧凑和皮实，适合老设备维护替换。
产品特点
0.75kW 小容量定位
额定输出 0.75kW，适配中小型电机，适合输送带、风机、小型机械这类普通调速场合。
V/F 控制简单可靠
采用 V/F 控制模式，不搞复杂算法，参数设置直观，调试门槛低，对普通工业应用来说够用。
紧凑小巧
体积小巧，适合老旧控制箱空间整合，不占地方。
IP20 防护
防护等级 IP20，装在控制柜里用，防尘能力一般，不能直接暴露在恶劣环境中。
已停产但维修价值高
这款已经停产多年，但在产线维修和维持原接线设计的情况下仍然实用，是延寿设备的选择。
产品参数
额定输出
0.75kW，1HP。
输入电源
三相 200 到 230V，50/60Hz。
额定电流
5A。
控制方式
V/F 控制。
输出频率
最大 400Hz。
过载能力
150% 持续 60 秒。
防护与环境
IP20，工作温度 -10 到 50 摄氏度。
尺寸重量
约 105 x 105 x 150 毫米，重约 0.65 到 1.44 公斤，不同来源略有差异。
应用领域
中小型输送系统
输送带、流水线这类需要简单调速的场合，V/F 控制够用，成本也低。
风机与水泵
普通风机水泵的调速控制，不需要太高精度，稳定运行就行。
裁切与打标设备
小型裁切机、打标机等设备的主轴或进给调速。
老旧设备维护替换
已经在跑 A024 系列的老设备，变频器坏了找同型号替换，参数和接线基本不用大改。
出口设备 UL 版本
有 UL 认证版本 FR-A024-0.75K-UL，适用于需要符合美规的出口设备或北美系统集成。
MITSUBISHI FR-A024-0.75K驱动变频器 英文介绍
MITSUBISHI FR-A024-0.75K is a classic small frequency converter from Mitsubishi FREQROL-A024 series, with a rated power of 0.75kW, which is 1HP. It adopts V/F control mode and is characterized by compactness and sturdiness, suitable for maintenance and replacement of old equipment.
Product Features
0.75kW small capacity positioning
Rated output of 0.75kW, suitable for small and medium-sized motors, suitable for ordinary speed control applications such as conveyor belts, fans, and small machinery.
V/F control is simple and reliable
Adopting V/F control mode, without complex algorithms, intuitive parameter settings, low debugging threshold, sufficient for ordinary industrial applications.
Compact and compact
Compact in size, suitable for integrating old control box space without taking up space.
IP20 protection
Protection level IP20, installed in the control cabinet, with average dust resistance and cannot be directly exposed to harsh environments.
Discontinued but with high maintenance value
This product has been discontinued for many years, but it is still practical for production line maintenance and maintaining the original wiring design, making it the choice for longevity equipment.
Product Specifications
rated output
0.75kW，1HP。
input power
Three phase 200 to 230V, 50/60Hz.
Rated current
5A。
Control method
V/F control.
output frequency
Maximum 400Hz.
overload capacity
150% for 60 seconds.
Protection and Environment
IP20， Working temperature -10 to 50 degrees Celsius.
Dimensions and Weight
Approximately 105 x 105 x 150 millimeters, weighing approximately 0.65 to 1.44 kilograms, with slight variations depending on the source.
Application Areas
Small and medium-sized conveying systems
For applications such as conveyor belts and assembly lines that require simple speed regulation, V/F control is sufficient and cost-effective.
Fan and water pump
The speed control of ordinary fan and water pump does not require high precision, and stable operation is sufficient.
Cutting and Marking Equipment
The spindle or feed speed regulation of small cutting machines, marking machines and other equipment.
Maintenance and replacement of old equipment
I am already running the A024 series old equipment, and if the frequency converter is broken, I need to replace it with the same model. The parameters and wiring basically do not need major changes.
Export equipment UL version
There is a UL certified version FR-A024-0.75K-UL, suitable for export equipment or North American system integration that requires compliance with US regulations.
MITSUBISHI FR-A024-0.75K驱动变频器 产品图片
