CAREL EVD0000T31双阀控制器 PDF资料

1.产 品 资 料 介 绍：

CAREL EVD0000T31 是卡乐 EVD Evolution Twin 系列的一款双阀控制器，核心特点是用一个控制器独立驱动两个电子膨胀阀。它属于 EVD0000T 系列，T31 这个后缀对应具体的通信和配置版本。

产品特点

双阀独立控制
内置两个双极步进电机驱动器，可以独立管理两个电子膨胀阀，分别调节各自的过热度，优化制冷回路性能。
过热度控制带多重保护
支持过热度控制，同时具备高压、低压和低过热度保护功能，防止压缩机液击和运行异常。
支持特殊控制功能
可以配置热气体旁通、蒸发器压力调节，以及跨临界 CO2 系统中气体冷却器下游阀门的控制。
图形 LCD 可拆卸
带可拆卸的图形 LCD 显示屏，支持多语言界面和参数在线帮助，还可以通过显示屏把配置参数从一个控制器复制到另一个。
调试简单
启动时只需选择 4 个参数，制冷剂、阀门类型、压力传感器类型、应用类型，如果用 CAREL 阀门则只需 3 个。

产品参数

型号归属
EVD Evolution Twin 系列，EVD0000T31。
阀门驱动
两个双极步进电机驱动器，独立控制两个电子膨胀阀。
安装方式
DIN 导轨安装，配可插拔螺钉端子。
压力传感器
支持 4 到 20 mA 比例式压力传感器，可多个驱动器共享。
通信与集成
可通过 LAN 连接 CAREL 控制器，支持 Digital Scroll 压缩机优化控制。

应用领域

冷水机组
控制蒸发器过热度，提升能效和运行稳定性。
空调系统
配合 Digital Scroll 压缩机做优化控制，适用于商用空调。
制冷设备
冷库、冷藏柜等制冷装置的电子膨胀阀控制。
CO2 跨临界系统
支持亚临界和跨临界 CO2 制冷回路，包括气体冷却器下游阀门控制。
多回路系统
一台控制器管两个回路，适合双回路或需要同时控制过热度与热气体旁通的场合。

EVD0000T31 的核心就是一控二，节省柜内空间和成本。选型时注意确认后缀 T31 对应的通信版本和现有系统的兼容性。

CAREL EVD0000T31双阀控制器  英文介绍

CAREL EVD0000T31 is a dual valve controller in the CAREL EVD Evolution Twin series, with the core feature of independently driving two electronic expansion valves with one controller. It belongs to the EVD0000T series, and the T31 suffix corresponds to specific communication and configuration versions.

Product Features

Dual valve independent control

Equipped with two bipolar stepper motor drivers, it can independently manage two electronic expansion valves, adjust their respective degrees of superheat, and optimize the performance of the refrigeration circuit.

Overheating control with multiple protections

Supports superheat control and has high pressure, low pressure, and low superheat protection functions to prevent compressor liquid hammer and abnormal operation.

Support special control functions

It can be configured with hot gas bypass, evaporator pressure regulation, and control of downstream valves of gas coolers in transcritical CO2 systems.

Graphic LCD detachable

Equipped with a detachable graphic LCD display screen, it supports multiple language interfaces and online parameter assistance, and can also copy configuration parameters from one controller to another through the display screen.

Easy debugging

When starting, only 4 parameters need to be selected: refrigerant, valve type, pressure sensor type, and application type. If using CAREL valve, only 3 parameters are required.

Product Specifications

Model attribution

EVD Evolution Twin series, EVD0000T31。

Valve drive

Two bipolar stepper motor drivers independently control two electronic expansion valves.

Installation Method

DIN rail installation, equipped with pluggable screw terminals.

Pressure sensor

Supports 4 to 20 mA proportional pressure sensors, which can be shared by multiple drivers.

Communication and Integration

CAREL controller can be connected via LAN, supporting optimized control of Digital Scroll compressor.

Application Areas

chiller

Control the superheat of the evaporator to improve energy efficiency and operational stability.

air conditioning system

Optimized control with Digital Scroll compressor, suitable for commercial air conditioning.

refrigeration equipment

Electronic expansion valve control for refrigeration devices such as cold storage and refrigerated cabinets.

CO2 transcritical system

Support subcritical and transcritical CO2 refrigeration circuits, including downstream valve control of gas coolers.

Multi loop system

One controller manages two circuits, suitable for dual circuits or situations where overheating and hot gas bypass need to be controlled simultaneously.

The core of EVD0000T31 is one control two, saving cabinet space and costs. When selecting, pay attention to confirming the compatibility between the communication version corresponding to suffix T31 and the existing system.

CAREL EVD0000T31双阀控制器 产品图片
