MITSUBISHI FX2N-48ET-DSS可编程控制器 PDF资料

1.产 品 资 料 介 绍：

MITSUBISHI FX2N-48ET-DSS 是三菱 FX2N 系列的一款扩展单元，不是基本单元。它自带电源，可以单独接在基本单元后面扩展 I/O，24 点输入加 24 点晶体管输出。

产品特点

自带电源的扩展单元
内置电源，能像基本单元一样继续往后接其他扩展模块或特殊功能模块，扩展起来比较灵活。
24 进 24 出
输入 24 点、输出 24 点，共 48 点，补 I/O 点数的时候直接加一块就行。
晶体管源型输出
输出是晶体管源型，响应快，适合需要频繁通断或者带脉冲型负载的场合。
DIN 导轨安装
标准导轨安装，拆装方便，柜内布局调整的时候不用大动干戈。
已停产但还在维修期
三菱官方显示这款已计划停产，但维修支持到 2035 年，老设备维护还能找到配件和维修服务。

产品参数

I/O 点数
输入 24 点，输出 24 点，共 48 点。
输出类型
晶体管输出，源型。
供电
DC 24V。
尺寸重量
宽 182 x 高 90 x 深 87 毫米，重 0.85 公斤。
工作温度
0 到 55 摄氏度。

应用领域

老设备 I/O 点数不够用
已经在跑 FX2N 系统的设备，控制点不够了，加一块 FX2N-48ET-DSS 直接扩出 24 进 24 出。
小型自动化产线
装配线、包装线上需要快速通断的场合，晶体管输出比继电器输出更适合频繁动作。
配合基本单元做控制柜扩充
控制柜里已经有 FX2N 基本单元，后续加传感器和气缸，用这块扩展单元补 I/O。
旧设备维护替换
FX2N 系统还在服役的工厂，扩展单元坏了找同型号替换，接线和程序基本不用改。
备件储备
做设备维保的，柜子里备一块这种还在维修期内的扩展单元，坏了直接换，省得停机等货。
FX2N-48ET-DSS 就是给 FX2N 系统补 I/O 用的 48 点扩展单元，24 进 24 出晶体管输出。

MITSUBISHI FX2N-48ET-DSS可编程控制器  英文介绍

MITSUBISHI FX2N-48ET-DSS is an extension unit of Mitsubishi FX2N series, not a basic unit. It comes with its own power supply and can be connected separately to the basic unit to expand I/O, with 24 point input and 24 point transistor output.

Product Features

Expansion unit with built-in power supply

Built in power supply, which can continue to be connected to other expansion modules or special function modules like a basic unit, making expansion more flexible.

24 in, 24 out

Input 24 points and output 24 points, a total of 48 points. When adding I/O points, simply add one block.

Transistor source output

The output is a transistor source type with fast response, suitable for situations that require frequent on-off or pulse type loads.

DIN rail installation

Standard guide rail installation, easy disassembly and assembly, no need to make big moves when adjusting the layout inside the cabinet.

Discontinued but still in maintenance period

Mitsubishi officials indicate that this model is planned to be discontinued, but maintenance support will be available until 2035, and parts and repair services can still be found for old equipment maintenance.

Product Specifications

I/O point count

Input 24 points, output 24 points, a total of 48 points.

output type

Transistor output, source type.

power supply

DC 24V。

Dimensions and Weight

Width 182 x height 90 x depth 87 millimeters, weight 0.85 kilograms.

Operating Temperature

0 to 55 degrees Celsius.

Application Areas

Insufficient I/O points for old devices

We are already running the FX2N system equipment and there are not enough control points. We need to add an FX2N-48ET-DSS to directly expand 24 in and 24 out.

Small automated production line

In situations where rapid switching is required on assembly lines and packaging lines, transistor output is more suitable for frequent operation than relay output.

Cooperate with the basic unit to expand the control cabinet

There is already an FX2N basic unit in the control cabinet, and sensors and cylinders will be added later. Use this expansion unit to supplement I/O.

Maintenance and replacement of old equipment

The FX2N system is still in service in the factory, and if the expansion unit is broken, it needs to be replaced with the same model. The wiring and program basically do not need to be changed.

Spare parts reserve

For equipment maintenance, keep an expansion unit in the cabinet that is still under repair. If it breaks, replace it directly to avoid downtime and waiting for delivery.

The FX2N-48ET-DSS is a 48 point expansion unit used to supplement I/O for the FX2N system, with 24 in and 24 out transistor outputs.

MITSUBISHI FX2N-48ET-DSS可编程控制器 产品图片
