Eurotherm 2132 100-240VAC温度控制器 PDF资料
Eurotherm 2132 是欧陆 2100 系列的一款紧凑型温度控制器，采用 1/32 DIN 面板尺寸，支持 85 到 264V AC 宽电压供电。它主打稳定精准的温度控制，自带自整定功能，适合各种简单的加热和冷却应用。
产品特点
1/32 DIN 紧凑尺寸
面板尺寸只有 48 x 24 毫米，是 2100 系列里最小的规格，装在空间紧张的控制柜里很合适。
PID 自整定控制
采用先进的 PID 算法提供稳定的直线型温度控制，自带自整定功能，不用专业知识就能优化控制效果。
通用输入兼容性强
支持九种标准热电偶类型、Pt100 热电阻，以及 4-20mA 线性输入，换传感器不用换控制器。
双输出可配置
两个输出可以灵活配置成加热、冷却或报警输出，配合外部继电器还能检测加热器故障。
三组内部报警
内置三个报警设定点，可以设成高限、低限或偏差报警，还支持启动时屏蔽报警避免误报。
产品参数
面板尺寸
1/32 DIN，48 宽 x 24 高 x 103 深 毫米。
供电电压
85 到 264V AC，最大功耗 5.0 瓦。
输入类型
九种热电偶、Pt100、4-20mA 线性输入。
输出规格
继电器 2A 264V AC 阻性，逻辑输出 9V DC 18mA。
防护与环境
IP65 前面板防护，工作温度 0 到 55 摄氏度，湿度 0 到 90% 不结露。
应用领域
塑料挤出
挤出机料筒和模具的温度控制，PID 算法保证温度稳定不波动。
冷却设备
冷水机、冷却器的温度监测和调节，配合冷却输出实现精准控温。
灭菌器
医疗和实验室灭菌设备的温度控制，三组报警提供多重安全保护。
小型烤箱
实验室烘箱、工业小烤箱的加热控制，自整定功能让调试更省事。
热封与伴热
包装热封机和管道伴热系统的温度管理，结构紧凑适合密集安装。
Eurotherm 2132 就是一款把 PID 控制、通用输入和紧凑尺寸做到平衡的温控器，适合空间有限但要求稳定控温的中小型加热冷却设备。
Eurotherm 2132 100-240VAC温度控制器 英文介绍
The Eurotherm 2132 is a compact temperature controller from the Eurotherm 2100 series, featuring a 1/32 DIN panel size and supporting a wide voltage supply of 85 to 264V AC. It focuses on stable and precise temperature control, with built-in self-tuning function, suitable for various simple heating and cooling applications.
Product Features
1/32 DIN compact size
The panel size is only 48 x 24 millimeters, which is the smallest specification in the 2100 series and is very suitable for installation in control cabinets with limited space.
PID self-tuning control
Adopting advanced PID algorithm to provide stable linear temperature control, with built-in self-tuning function, the control effect can be optimized without professional knowledge.
Strong universal input compatibility
Supports nine standard thermocouple types, Pt100 thermistor, and 4-20mA linear input, eliminating the need to replace the controller when changing sensors.
Dual output configurable
The two outputs can be flexibly configured as heating, cooling, or alarm outputs, and can also detect heater faults when combined with external relays.
Three internal alarms
Built in three alarm setpoints, which can be set as high limit, low limit, or deviation alarm. It also supports masking alarms during startup to avoid false alarms.
Product Specifications
Panel Size
1/32 DIN， 48 wide x 24 high x 103 deep millimeters.
power supply voltage
85 to 264V AC, maximum power consumption of 5.0 watts.
input type
Nine types of thermocouples, Pt100, 4-20mA linear input.
Output Specification
Relay 2A 264V AC resistive, logic output 9V DC 18mA.
Protection and Environment
IP65 front panel protection, working temperature from 0 to 55 degrees Celsius, humidity from 0 to 90% without condensation.
Application Areas
Plastic extrusion
The temperature control of the extruder barrel and mold is ensured by PID algorithm to maintain stable temperature without fluctuations.
cooling equipment
Temperature monitoring and regulation of chillers and coolers, combined with cooling output to achieve precise temperature control.
sterilizer
Temperature control of medical and laboratory sterilization equipment, with three sets of alarms providing multiple safety protections.
Small oven
The heating control and self-tuning function of laboratory ovens and industrial small ovens make debugging more convenient.
Heat sealing and heat tracing
The temperature management of packaging heat sealing machine and pipeline tracing system is compact in structure and suitable for intensive installation.
Eurotherm 2132 is a temperature controller that balances PID control, universal input, and compact size, suitable for small and medium-sized heating and cooling equipment with limited space but stable temperature control requirements.
Eurotherm 2132 100-240VAC温度控制器 产品图片
