YASKAWA CIMR-J7AZB1P5逆变器驱动器 PDF资料

1.产 品 资 料 介 绍：

YASKAWA CIMR-J7AZB1P5 是安川 VS mini J7 系列的一款小型通用变频器，单相 200V 输入，适配 1.5kW 电机。它属于 J7 家族里的单相基本型号，主打紧凑、低成本、简单好用。

产品特点

单相 200V 输入带 1.5kW 电机
输入是单相 200 到 240V，输出三相给电机用，适配 1.5kW 电机，额定输出电流 8A。
V/f 控制简单直接
采用正弦波 PWM 的 V/f 控制方式，不玩复杂算法，参数设置直观，适合泵、风机、传送带这类普通调速场合。
数字操作器带电位器
面板上自带数字操作器和频率电位器，不用外接就能调频率、看状态、改参数，调试门槛低。
9 段速和模拟量输入
支持最多 9 段速运行，可以预存多个频率值切换。外部频率给定支持 0 到 10V 电压和 4 到 20mA 电流信号。
紧凑 IP20 塑料壳
防护等级 IP20，只能装在控制柜里。体积小，可以选配 DIN 导轨安装附件，柜内占地方少。

产品参数

输入规格
单相 200 到 240V AC，50/60Hz。
输出规格
三相 200 到 240V，0.1 到 400Hz，额定电流 8A，适配 1.5kW 电机。
控制方式
正弦波 PWM，V/f 控制。
过载能力
150% 额定电流持续 1 分钟。
防护与环境
IP20，工作温度零下 10 度到正 50 度。

应用领域

泵与风机调速
最常见的就是控制水泵和风机的转速，根据实际需求调流量，比阀门挡板省电。
传送带与物料搬运
传送带需要软启动、平稳加减速的场合，J7 的加减速时间可设，启动冲击小。
搅拌机与混合设备
搅拌工艺需要不同转速适配不同物料，9 段速功能可以预存几个常用转速直接切换。
小型机械配套
包装机、绕线机、小型机床这类设备，配一台 1.5kW 以下电机，J7 性价比合适。
老设备维护替换
已经在跑 J7 系列变频器的老设备，坏了找同型号替换，参数和接线不用大改。注意 J7 是安川的 legacy 产品，已经不主推了。
CIMR-J7AZB1P5 的核心定位就是单相 200V、1.5kW 的小型通用变频器，功能不花哨但够用，胜在便宜紧凑

SICK WLG12-P537 开关式自动化光栅  英文介绍

YASKAWA CIMR-J7AZB1P5 is a small universal frequency converter from the Yaskawa VS mini J7 series, with a single-phase 200V input and suitable for 1.5kW motors. It belongs to the single-phase basic model in the J7 family, focusing on compactness, low cost, and simplicity.

Product Features

Single phase 200V input with 1.5kW motor

The input is single-phase 200 to 240V, and the output is three-phase for the motor. It is compatible with a 1.5kW motor and has a rated output current of 8A.

V/f control is simple and direct

The V/f control method adopts sine wave PWM, without playing complex algorithms, with intuitive parameter settings, suitable for ordinary speed regulation occasions such as pumps, fans, and conveyor belts.

Digital operator with potentiometer

The panel comes with a digital operator and frequency potentiometer, allowing for frequency adjustment, status monitoring, and parameter modification without the need for external connections. The debugging threshold is low.

9-speed and analog input

Supports up to 9-speed operation and can pre store multiple frequency values for switching. The external frequency setting supports 0 to 10V voltage and 4 to 20mA current signals.

Compact IP20 plastic shell

Protection level IP20, can only be installed in the control cabinet. Small size, can be equipped with DIN rail mounting accessories, and takes up less space inside the cabinet.

Product Specifications

Input specifications

Single phase 200 to 240V AC, 50/60Hz.

Output Specification

Three phase 200 to 240V, 0.1 to 400Hz, rated current 8A, suitable for 1.5kW motor.

Control method

Sine wave PWM, V/f control.

overload capacity

150% rated current for 1 minute.

Protection and Environment

IP20， The working temperature ranges from minus 10 degrees Celsius to plus 50 degrees Celsius.

Application Areas

Pump and fan speed regulation

The most common method is to control the speed of the water pump and fan, adjust the flow rate according to actual needs, which is more energy-efficient than valve baffles.

Conveyor belts and material handling

When the conveyor belt requires soft start and smooth acceleration and deceleration, the acceleration and deceleration time of J7 can be set, and the starting impact is small.

Blender and mixing equipment

The mixing process requires different speeds to adapt to different materials, and the 9-speed function can pre store several commonly used speeds for direct switching.

Small machinery matching

Equipment such as packaging machines, winding machines, and small machine tools, equipped with a motor below 1.5kW, J7 is cost-effective.

Maintenance and replacement of old equipment

I am already running the old equipment of J7 series frequency converter. If it breaks down, I will replace it with the same model, and there is no need to make major changes to the parameters and wiring. Note that J7 is a legacy product of Yaskawa and is no longer being promoted.

The core positioning of CIMR-J7AZB1P5 is a small universal frequency converter with single-phase 200V and 1.5kW. Its functions are not fancy but sufficient, and it excels in being cheap and compact

SICK WLG12-P537 开关式自动化光栅 产品图片
