MITSUBISHI FX1N-40MT-DSS可编程控制器 PDF资料

1.产 品 资 料 介 绍：

MITSUBISHI FX1N-40MT-DSS 是三菱电机 MELSEC-FX 系列里的一款小型可编程控制器，属于 FX1N 家族里的 40 点基本单元。它自带 24 个输入和 16 个晶体管输出，用 24V 直流供电，主打紧凑和高速响应。

产品特点

晶体管输出响应快
后缀里的 MT 代表晶体管输出，适合驱动伺服电机、步进电机或者需要高速脉冲输出的场合，比继电器输出寿命长、响应快。

24 进 16 出配置
一共 40 个 I/O 点，输入 24 点、输出 16 点，基本单元就能满足中小型设备的控制需求，不够还能加扩展模块。

8K 步程序内存
内置 8000 步 EEPROM 存储器，掉电不用电池也能保住程序，省了维护电池的麻烦。

实时时钟功能
自带时钟，可以做定时控制、时间戳记录这类需要日期时间的逻辑，备用电源靠大电容撑住，通一次电能用十来天。

紧凑 DIN 导轨安装
尺寸大概 130 x 90 x 75 毫米，重 0.65 公斤左右，直接卡在 DIN 导轨上就行，控制柜里不占地方。

产品参数

I/O 点数
输入 24 点，输出 16 点，共 40 点。

输出类型
晶体管输出，支持高速脉冲，适合运动控制。

供电电压
12 到 24V 直流。

程序容量
8000 步 EEPROM。

工作温度
0 到 55 摄氏度，湿度 35% 到 85% 不结露，防护等级 IP20。

应用领域

自动换刀系统
用在加工中心的链式刀库控制上，输出高速脉冲驱动伺服电机带动刀库旋转定位，同时控制气缸完成刀套翻转和机械手换刀。

教学实训设备
很多 PLC 实训台用 FX1N-40MT 做载体，比如抢答器电路设计、基础逻辑编程训练，学生上手快、接线直观。

自动洗车设备
有项目用它来控制自动洗车系统的传送带、水泵、风机和多个电机，配合传感器完成整个洗车流程。

小型自动化设备
包装、贴标、简单的工位控制这类场景，24 进 16 出够用，晶体管输出又能直接带脉冲型驱动器。

老旧设备维护替换
已经在跑 FX1N 系统的老设备，控制器坏了找同型号替换就行，程序和接线基本不用动。

FX1N-40MT-DSS 就是三菱 FX1N 系列里 40 点晶体管输出的基本单元，24V 直流供电，自带时钟和 8K 程序容量。它适合需要高速脉冲输出的小型运动控制场合

MITSUBISHI FX1N-40MT-DSS可编程控制器  英文介绍

MITSUBISHI FX1N-40MT-DSS is a small programmable controller in the Mitsubishi Electric MELSEC-FX series, belonging to the 40 point basic unit of the FX1N family. It comes with 24 inputs and 16 transistor outputs, powered by 24V DC, and features compact and high-speed response.

Product Features

Fast response of transistor output

The MT in the suffix represents transistor output, suitable for driving servo motors, stepper motors, or situations that require high-speed pulse output. It has a longer lifespan and faster response than relay output.

24 in 16 out configuration

There are a total of 40 I/O points, with 24 input points and 16 output points. The basic unit can meet the control needs of small and medium-sized devices, and if not, additional expansion modules can be added.

8K step program memory

Equipped with an 8000 step EEPROM memory, the program can be saved even in the event of a power failure without the need for a battery, saving the trouble of battery maintenance.

Real time clock function

Equipped with a built-in clock, it can perform timing control, timestamp recording, and other logic that requires date and time. The backup power supply is supported by a large capacitor, and it takes about ten days to power on once.

Compact DIN rail installation

The size is approximately 130 x 90 x 75 millimeters, weighing around 0.65 kilograms. Simply clamp it onto the DIN rail and it won't take up space inside the control cabinet.

Product Specifications

I/O point count

Input 24 points, output 16 points, for a total of 40 points.

output type

Transistor output, supports high-speed pulses, suitable for motion control.

power supply voltage

12 to 24V DC.

Program capacity

8000 step EEPROM.

Operating Temperature

0 to 55 degrees Celsius, humidity 35% to 85%, no condensation, protection level IP20.

Application Areas

Automatic tool changing system

Used in the chain tool magazine control of machining centers, it outputs high-speed pulses to drive servo motors to rotate and position the tool magazine, while controlling the cylinder to complete the flipping of the tool sleeve and the tool change of the robotic arm.

Teaching and training equipment

Many PLC training platforms use FX1N-40MT as a carrier, such as buzzer circuit design and basic logic programming training. Students can quickly get started and have intuitive wiring.

Automatic car washing equipment

A project uses it to control the conveyor belt, water pump, fan, and multiple motors of an automatic car washing system, and complete the entire car washing process with sensors.

Small scale automation equipment

In scenarios such as packaging, labeling, and simple workstation control, 24 in 16 out is sufficient, and transistor output can be directly driven by pulse type drivers.

Maintenance and replacement of old equipment

The old device that is already running the FX1N system, if the controller is broken, just replace it with the same model, and there is basically no need to move the program and wiring.

FX1N-40MT-DSS is the basic unit of Mitsubishi FX1N series with 40 point transistor output, powered by 24V DC, equipped with clock and 8K program capacity. It is suitable for small motion control applications that require high-speed pulse output

MITSUBISHI FX1N-40MT-DSS可编程控制器 产品图片
