TRANE X13650476-10 控制模块 PDF资料
TRANE X13650476-10 是特灵冷水机组上的一块控制模块板卡，属于 1U1 控制器模块。它本身是电路板级别的部件，装在特灵空调或冷水机的控制柜里，负责机组的逻辑控制和参数管理。
产品特点
冷水机组专用控制板
这块板子是特灵冷水机控制系统里的核心模块，通常标为 1U1 位置，负责机组的运行控制和状态监测。
直接替换设计
替换原厂板卡时是线对线、插头对插头、连接器对连接器的直接替换，不用改接线，安装比较省事。
支持升级显示
早期机型用的编码显示，换装这块 1U1 模块之后可以升级到 Clear Language Display 文本显示控制器，操作界面更直观。
带泵输出端子
替换用的 1U1 模块上多了一个泵输出端子，安装的时候可以直接利用上。
市场流通以二手翻新为主
这块板子目前主要出现在二手和拆机市场，价格比原厂新板低不少，适合老设备维修替换。
产品参数
产品类别
HVAC 控制模块板卡，冷水机组控制器。
对应型号
X13650476-10 REV N，也有 X13650476-10N 的写法。
关联零件号
6200-0049-13。
物理重量
大约 4 磅，折合 1.8 公斤左右。
适用机型
特灵 RTAA、RTAD、RTAC、YAFR 等系列冷水机。
应用领域
特灵冷水机组维修
RTAA、RTAD、RTAC 这些老款特灵冷水机控制出问题，换这块 1U1 板子是最直接的修复方式。
旧机控制系统升级
早期用编码显示的 RTAA 130 到 400 冷量机型，换这块板子可以升级到文本显示控制器。
空调系统维保备件
做商用空调维保的，手里备一块这种板子，遇到控制故障可以先对换测试，不用等原厂订货。
二手拆机市场流通
这块板子主要从拆解的 YAFR、RTAD 等冷水机上拆下来流通，适合预算有限的维修场景。
X13650476-10 本质上就是特灵冷水机控制柜里的 1U1 控制模块板卡，专给老款特灵冷水机做维修替换和显示升级用
TRANE X13650476-10 is a control module board on the Trane chiller unit, belonging to the 1U1 controller module. It is a circuit board level component installed in the control cabinet of a Trane air conditioner or chiller, responsible for the logic control and parameter management of the unit.
Product Features
Special control board for chiller unit
This board is the core module in the control system of the Trane chiller, usually marked at the 1U1 position, responsible for the operation control and status monitoring of the unit.
Directly replace the design
When replacing the original board, it is a direct replacement of wire to wire, plug to plug, and connector to connector without changing the wiring, making installation more convenient.
Support upgrading display
The coding display used in early models can be upgraded to a Clear Language Display text display controller after installing this 1U1 module, making the operating interface more intuitive.
Equipped with pump output terminal
The 1U1 module used for replacement has an additional pump output terminal, which can be directly utilized during installation.
The market circulation is mainly dominated by second-hand renovations
This board is currently mainly available in the second-hand and dismantling markets, with a much lower price than the original new board, making it suitable for repairing and replacing old equipment.
Product Specifications
Product Category
HVAC control module board, chiller controller.
corresponding model
X13650476-10 REV N， There is also a writing style of X13650476-10N.
Associated part number
6200-0049-13.
Physical weight
About 4 pounds, equivalent to about 1.8 kilograms.
Applicable models
Trane RTAA, RTAD, RTAC, YAFR and other series of chillers.
Application Areas
Trane chiller maintenance
The most direct way to fix the control problems of old models of Trane chillers such as RTAA, RTAD, and RTAC is to replace this 1U1 board.
Upgrade of old machine control system
The RTAA 130 to 400 cooling capacity models that used coding display in the early days can be upgraded to text display controllers by replacing this board.
Maintenance spare parts for air conditioning system
For those who do commercial air conditioning maintenance, keep a board of this type in hand. If you encounter a control failure, you can exchange it for testing first, without waiting for the original factory to place an order.
Circulation in the second-hand dismantling market
This board is mainly disassembled from YAFR, RTAD and other chillers for circulation, suitable for maintenance scenarios with limited budgets.
X13650476-10 is essentially a 1U1 control module board in the control cabinet of the Trane chiller, specifically designed for maintenance, replacement, and display upgrades of older Trane chillers
