BOSCH PE2189/01 052910-309电源模块 PDF资料
BOSCH PE2189/01 052910-309 这块板子，其实是一块电源模块，属于 Bosch 早期 CNC 系统 PS 200 电源里的电路板部件。它本身是个电路板级别的电源模块，不是那种独立带壳的电源，主要用在老款 Bosch 数控设备或者 Indramat 驱动系统里做供电。
产品特点
板级电源模块
这块板子是 PS 200 电源装置内部的核心电路板，负责把输入电压转换成系统需要的多路直流输出，不是独立成壳的电源单元。
5V 大电流输出
从型号信息看，它主要提供 5V 输出，电流能力标到 22.5A，属于大电流低压输出，给逻辑电路和接口供电用。
开关电源架构
归类属于开关电源，效率比线性电源高，发热相对小一些，适合装在控制柜内部。
原厂板卡替换件
它是 Bosch 原厂编号 052910-309110 的板卡，主要用途是维修替换，不是新设计选型用的产品。
工业环境适用
设计上就是给工业 CNC 和驱动系统用的，工作环境是控制柜内部，对温湿度和防护没有独立电源那么高的要求。
产品参数
输出规格
5V DC，最大 22.5A。
产品类别
开关电源，板卡形态。
关联型号
PS 200 电源装置，零件号 052910-309110。
物理形态
电路板，非独立机壳封装，重量大概 2.8 kg 左右（含板卡和安装件）。
原厂归属
Bosch / Indramat 体系，属于 CNC 电源模块。
应用领域
Bosch CNC 系统维护
老款 Bosch 数控系统电源坏了，直接换这块板卡是最快的修复方式。
Indramat 驱动系统供电
Indramat 驱动系统配套的 PS 200 电源里用的就是这块板子，驱动器供电异常时可以检查或替换它。
老设备维修替换
工厂里还在跑的 Bosch 老机床、老驱动柜，电源板出问题基本都是找这种原厂编号的板卡来换。
工控电源维修备件
做工业电子维修的，手里备一块这种板子，遇到 PS 200 电源故障可以直接对换测试，省得等原厂报价。
二手/翻新市场流通
这块板子目前主要在二手和翻新市场流通，价格比新板便宜不少，适合预算有限的维修场景。
PE2189/01 052910-309 本质上就是 PS 200 电源的 5V 大电流输出板卡，专给老 Bosch CNC 和 Indramat 系统做维修替换用
BOSCH PE2189/01 052910-309电源模块 英文介绍
The BOSCH PE2189/01 052910-309 board is actually a power module, which belongs to the circuit board components of Bosch's early CNC system PS 200 power supply. It is a power module at the level of a circuit board, not a standalone power supply with a casing. It is mainly used for power supply in old Bosch CNC equipment or Indramat drive systems.
Product Features
Board level power module
This board is the core circuit board inside the PS 200 power supply device, responsible for converting input voltage into multiple DC outputs required by the system, and is not a standalone power unit.
5V high current output
From the model information, it mainly provides 5V output with a current capacity of 22.5A, belonging to high current and low voltage output, used for supplying power to logic circuits and interfaces.
Switching power supply architecture
Classified as a switch mode power supply, it has higher efficiency than linear power supplies and relatively less heat generation, making it suitable for installation inside control cabinets.
Original factory board replacement parts
It is a Bosch original factory board with the serial number 052910-309110, mainly used for maintenance and replacement, not for new design and selection.
Suitable for industrial environments
Designed for industrial CNC and drive systems, the working environment is inside the control cabinet, and there are not as high requirements for temperature, humidity, and protection as independent power sources.
Product Specifications
Output Specification
5V DC， Maximum 22.5A.
Product Category
Switching power supply, board form.
Associated model
PS 200 power supply unit, part number 052910-309110.
Physical form
Circuit board, not packaged in a standalone chassis, weighing approximately 2.8 kg (including board and mounting components).
Original factory ownership
Bosch/Indramat system, belonging to CNC power module.
Application Areas
Bosch CNC system maintenance
The old Bosch CNC system power supply is broken, replacing this board directly is the fastest way to repair it.
Indramat drive system power supply
This board is used in the PS 200 power supply that comes with the Indramat drive system. It can be checked or replaced in case of abnormal power supply to the drive.
Old equipment maintenance and replacement
The Bosch old machine tools and drive cabinets that are still running in the factory, and the power boards that have problems, are basically replaced with original factory numbered boards.
Industrial control power supply maintenance spare parts
For those who do industrial electronic maintenance, keep a board of this kind in hand. If you encounter a PS 200 power failure, you can directly exchange it for testing, saving you from waiting for the original factory quotation.
Circulation in the second-hand/refurbished market
This board is currently mainly circulated in the second-hand and refurbished markets, and its price is much cheaper than new boards, making it suitable for maintenance scenarios with limited budgets.
PE2189/01 052910-309 is essentially a 5V high current output board for PS 200 power supply, specifically designed for maintenance and replacement of old Bosch CNC and Indramat systems
BOSCH PE2189/01 052910-309电源模块 产品图片
