BECKHOFF CX9020-0111 嵌入式PC/CPU模块 PDF资料
BECKHOFF CX9020-0111 这个型号就是倍福 CX9020 系列里预装了 Windows Embedded Compact 7 系统和 TwinCAT 2 PLC 运行时的基本 CPU 模块。它用的是 ARM 架构处理器，主打紧凑省电皮实，适合中小型控制任务。
产品特点
处理器省电
ARM Cortex-A8 处理器，1 GHz 主频，带硬件浮点单元，整机功耗最大才 5 W 左右。
总线自动识别
集成了倍福 I/O 接口，能自动识别接的是 E-bus 还是 K-bus 端子模块，自己切换不用手动配。
无风扇散热
靠铝壳自然散热，没有风扇，粉尘大的车间里少一个会坏的机械部件。
接口够用
两个 RJ45 网口内部已经连好交换机，做线型拓扑直接串就行。还有四个 USB 口和一个 DVI 视频口。
宽温工作
工作温度负 25 度到正 60 度，一般控制柜里用绰绰有余，环境差一点也能扛。
产品参数
处理器
ARM Cortex-A8，1 GHz，单核。
内存
1 GB DDR3 RAM，板载不能扩。128 kB NOVRAM 存掉电数据。
存储
两个 microSD 卡插槽，出厂带 512 MB 卡。
接口
两个 10/100 M 网口，四个 USB 2.0，一个 DVI-D，一个可选接口位。
电源防护
24 V DC 供电，防护等级 IP20，只能装控制柜里。
应用领域
中小型设备控制
包装机、贴标机、简单装配工位这类设备的 PLC 和运动控制。
楼宇自动化
暖通空调、灯光场景管理，带 DVI 口可以直接接显示器做可视化。
风电户外设备
宽温范围适合风力发电机组控制柜、太阳能追踪系统这些环境恶劣的地方。
测试台实验室
跑一些需要数学运算的控制算法，做数据采集和简单闭环控制。
分布式控制节点
体积小支持线型拓扑，可以分散装在设备不同位置当本地控制器。
总的来说 CX9020-0111 就是那种不占地方又能扛事的小型控制器，旧设备维护替换选它比较稳妥，新项目的话可以顺便问问倍福有没有更新一代的替代型号。
BECKHOFF CX9020-0111 嵌入式PC/CPU模块 英文介绍
The BECKHOFF CX9020-0111 model is the basic CPU module that comes pre installed with the Windows Embedded Compact 7 system and TwinCAT 2 PLC runtime in the Beifu CX9020 series. It uses an ARM architecture processor, which focuses on compact, power-saving, and practical design, suitable for small and medium-sized control tasks.
Product Features
Processor power-saving
ARM Cortex-A8 processor, 1 GHz clock speed, with hardware floating-point unit, maximum power consumption of the whole machine is only about 5 W.
Bus automatic recognition
Integrated with Beifu I/O interface, it can automatically identify whether it is connected to E-bus or K-bus terminal module, and can switch by oneself without manual configuration.
fanless cooling
By relying on aluminum shells for natural heat dissipation, without fans, workshops with high dust levels will have one less mechanical component that could break.
The interface is sufficient
Two RJ45 network ports have already been connected to the switch internally, and a linear topology can be directly connected in series. There are also four USB ports and one DVI video port.
Wide temperature operation
The working temperature ranges from negative 25 degrees to positive 60 degrees, which is generally more than enough for use in control cabinets, and can withstand even slightly worse environments.
Product Specifications
Processor
ARM Cortex-A8，1 GHz， Single core.
Memory
1 GB DDR3 RAM， The board cannot be expanded. 128 kB NOVRAM stores power down data.
storage
Two microSD card slots, with a factory included 512 MB card.
interface
Two 10/100M Ethernet ports, four USB 2.0 ports, one DVI-D port, and one optional interface bit.
power protection
24 V DC power supply, protection level IP20, can only be installed in the control cabinet.
Application Areas
Small and medium-sized equipment control
PLC and motion control for equipment such as packaging machines, labeling machines, and simple assembly stations.
Building Automation
HVAC and lighting scene management, with DVI port that can be directly connected to a monitor for visualization.
Wind power outdoor equipment
The wide temperature range is suitable for harsh environments such as wind turbine control cabinets and solar tracking systems.
Test bench laboratory
Run some control algorithms that require mathematical operations, perform data collection and simple closed-loop control.
Distributed Control Node
Small in size, supports linear topology, and can be installed in different locations on the device as a local controller.
Overall, CX9020-0111 is the type of small controller that doesn't take up space and can handle tasks. It's more reliable to choose it for maintenance and replacement of old equipment. For new projects, you can also ask if Beifu has updated a replacement model for the next generation.
BECKHOFF CX9020-0111 嵌入式PC/CPU模块 产品图片
