KEYENCE CA-E100输入模块 PDF资料

1.产 品 资 料 介 绍：

基恩士 CA-E100 是基恩士机器视觉系统里的相机输入模块，说白了就是给视觉控制器加相机接口的扩展单元。

产品特点

1. 相机输入扩展模块，控制器本身不带相机接口，CA-E100 就是用来插相机的，装在 XG-X 或 VS-G 系列视觉控制器上。

2. 一台接两个相机，单个 CA-E100 模块可以接 2 台面阵相机，多买几个模块就能扩展更多路相机。

3. 即插即用，作为视觉系统的扩展单元，插上控制器就能用，不用额外折腾配置。

4. 高速图像传输，支持高速图像数据传输，适合在线检测这种对速度有要求的场景。

5. 工业级设计，结构紧凑，适合工业现场环境，装在电柜或者视觉系统的机架上就行。

产品参数

1. 类型：面阵相机输入模块。

2. 相机接口数：每模块 2 个。

3. 兼容控制器：基恩士 XG-X 系列、VS-G 系列、CV-X 系列视觉控制器。

4. 供电：24V 直流，电流约 5.3A。

5. 系统最大扩展：单个控制器最多装 2 个 CA-E100，也就是最多 4 台相机。

应用领域

1. 机器视觉和自动检测系统，多相机设置做质量检查。

2. 多角度检测，需要从不同位置同时拍同一个工件的场合。

3. 机器人和包装应用，需要精确成像的自动化产线。

4. 电子制造检测，配合基恩士视觉系统做外观和定位检查。

5. 产线在线检测，高速生产线上做实时图像采集和判断。

总的来说，CA-E100 就是基恩士视觉系统的一个相机扩展口，控制器本身没相机接口，得靠它来接相机。一台模块接两个相机，不够就再加一块，最多四路。用在多相机检测的产线上挺合适。

KEYENCE CA-E100输入模块  英文介绍

The Keyence CA-E100 is a camera input module in the Keyence machine vision system, which is essentially an extension unit that adds a camera interface to the vision controller.

Product Features

Camera input expansion module, the controller itself does not have a camera interface, CA-E100 is used to plug in the camera and is installed on XG-X or VS-G series visual controllers.

One camera can connect to two cameras, and a single CA-E100 module can connect to two array cameras. Buying a few more modules can expand more cameras.

Plug and play, as an extension unit of the visual system, it can be used by plugging in the controller without the need for additional configuration.

High speed image transmission, supporting high-speed image data transmission, suitable for online detection scenarios that require speed.

Industrial grade design, compact structure, suitable for industrial site environment, can be installed on the rack of electrical cabinets or visual systems.

Product Specifications

Type: Area array camera input module.

Number of camera interfaces: 2 per module.

Compatible controllers: Keyence XG-X series, VS-G series, CV-X series visual controllers.

Power supply: 24V DC, current approximately 5.3A.

Maximum system expansion: A single controller can accommodate up to 2 CA-E100 cameras, which means a maximum of 4 cameras.

Application Areas

Machine vision and automatic inspection system, with multiple camera settings for quality inspection.

Multi angle detection requires simultaneous shooting of the same workpiece from different positions.

Robots and packaging applications require automated production lines with precise imaging.

Electronic manufacturing inspection, combined with Keyence visual system for appearance and positioning inspection.

Online detection of production lines, real-time image acquisition and judgment on high-speed production lines.

Overall, CA-E100 is a camera expansion port for the Keyence Vision System. The controller itself does not have a camera interface and relies on it to connect to the camera. Connect two cameras to one module, if not enough, add another one, up to four channels at most. It is quite suitable for use on multi camera detection production lines.

KEYENCE CA-E100输入模块 产品图片
