YASKAWA SGDV-5R4D11A020000伺服驱动器 PDF资料

1.产 品 资 料 介 绍：

安川 SGDV-5R4D11A020000 是 Σ-V 系列里的 MECHATROLINK-II 通信指令型伺服驱动器，属于 400V 三相、1.5kW 这个级别。

产品特点

1. MECHATROLINK-II 通信，通过高速总线跟上位控制器通信，一根线搞定，省掉了脉冲发生器或者模拟量指令那堆接线。

2. 多合一控制，转矩、位置、速度控制都能干，还能在线切换控制模式，复杂的机械动作也能平滑搞定。

3. 高速高精度，支持同步相位控制，通信周期可以设到 250μs 到 4ms，适合对响应有要求的场合。

4. 在线自动调整，能根据机械特性自动调整参数，不用费劲手动折腾，上手快。

5. 省配线，一条通信线最多能连 30 个站，接线成本和时间都省不少。

产品参数

1. 适用电机容量：1.5kW。

2. 电源电压：三相 AC400V。

3. 输出电流：额定 5.4A，型号里的 5R4 就是这个意思。

4. 通信接口：MECHATROLINK-II 通信指令型，旋转型伺服电机用。

5. 硬件选配：DB 电阻外置型。

应用领域

1. 机床进给轴，各种机床的进给驱动，高速进给场合也能应付。

2. 传送和搬运机械，产线上的传送装置、搬运设备的轴驱动。

3. 食品加工机械，食品加工设备的伺服轴控制。

4. 贴片机和 PCB 打孔机，电子制造设备里需要快速精确定位的轴。

5. 印刷电路板相关设备，精密定位和高速往复运动的场合。

总的来说，SGDV-5R4D11A020000 就是安川 Σ-V 系列里走 MECHATROLINK-II 总线的 1.5kW 伺服驱动器，接线省、调整方便、控制模式灵活。用在机床或者自动化产线的进给轴上挺合适。

YASKAWA SGDV-5R4D11A020000伺服驱动器  英文介绍

Yaskawa SGDV-5R4D11A02000 is a MECHATROLINK-II communication command servo drive in the ∑ - V series, belonging to the 400V three-phase, 1.5kW class.

Product Features

MECHATROLINK-II communication, communicates with the upper controller through a high-speed bus, can be done with one wire, eliminating the need for pulse generators or analog command wiring.

Multi in one control, capable of controlling torque, position, and speed, and can also switch control modes online. Complex mechanical actions can be smoothly handled.

High speed and high precision, supporting synchronous phase control, communication cycle can be set to 250 μ s to 4ms, suitable for occasions with response requirements.

Online automatic adjustment, capable of automatically adjusting parameters based on mechanical characteristics, without the need for manual labor, making it easy to get started.

Provincial wiring, one communication line can connect up to 30 stations, saving a lot of wiring costs and time.

Product Specifications

Applicable motor capacity: 1.5kW.

Power supply voltage: three-phase AC400V.

Output current: rated 5.4A, 5R4 in the model refers to this.

Communication interface: MECHATROLINK-II communication command type, used for rotary servo motors.

Hardware selection: DB resistor external type.

Application Areas

Machine tool feed axis, various machine tool feed drives, can also handle high-speed feed situations.

Conveyor and handling machinery, shaft drives for conveyor devices and handling equipment on production lines.

Servo axis control for food processing machinery and equipment.

SMT machines and PCB punching machines are axes in electronic manufacturing equipment that require fast and precise positioning.

Printed circuit board related equipment for precise positioning and high-speed reciprocating motion.

In general, the SGDV-5R4D11A02000 is a 1.5kW servo drive in the Yaskawa ∑ - V series that uses the MECHATROLINK-II bus, with low wiring, easy adjustment, and flexible control modes. It is quite suitable for use on the feed axis of machine tools or automated production lines.

YASKAWA SGDV-5R4D11A020000伺服驱动器 产品图片
