FANUC A06B-6093-H112伺服放大器模块 PDF资料
发那科 A06B-6093-H112 是 β 系列里的 SVU-20 单轴伺服放大器，专门驱动中小型伺服电机。
产品特点
SVU-20 单轴驱动，带内置电源，驱动 20 级别 β 系列伺服电机。
FSSB 光纤接口，和 CNC 通信响应快，一根光纤搞定。
伺服参数存在驱动器板子上，换件前得先备份参数，不然轴没法正常干活。
风冷设计，装在电柜里垂直或壁挂都行。
内置过载和过流保护，电流异常能自己断掉。
产品参数
输出电流：额定 5.9 安培，最大输出电压 240V 交流。
输入电源：单相或三相 200 到 240V 交流，50/60Hz。
接口类型：FSSB 光纤接口。
工作温度：0 到 55 度。
重量：大概 1.32 公斤。
应用领域
小型数控机床的进给轴或辅助轴。
小型工业机器人的定位轴或旋转轴。
加工中心的刀库旋转和自动换刀机构。
分度盘和转台的驱动轴。
发那科 16/18/21 系列系统上维修替换用。
总的来说，A06B-6093-H112 就是发那科 β 系列里的 SVU-20 单轴驱动器，风冷、光纤接口、5.9A 输出，驱动中小型伺服电机。换件时记得先备份参数，不然装上去轴动不了。
FANUC A06B-6093-H112伺服放大器模块 英文介绍
Fanuc A06B-6093-H112 is an SVU-20 single axis servo amplifier in the β series, specifically designed to drive small and medium-sized servo motors.
Product Features
SVU-20 single axis drive with built-in power supply, driving 20 level β series servo motors.
FSSB fiber optic interface, fast communication response with CNC, can be handled with just one fiber optic cable.
The servo parameters are stored on the drive board, so it is necessary to backup the parameters before replacing them, otherwise the shaft cannot work properly.
Air cooling design, can be installed vertically or wall mounted in the electrical cabinet.
Built in overload and overcurrent protection, capable of self disconnection in case of abnormal current.
Product Specifications
Output current: rated 5.9 amperes, maximum output voltage 240V AC.
Input power supply: single-phase or three-phase 200 to 240V AC, 50/60Hz.
Interface type: FSSB fiber optic interface.
Working temperature: 0 to 55 degrees.
Weight: Approximately 1.32 kilograms.
Application Areas
The feed axis or auxiliary axis of small CNC machine tools.
The positioning axis or rotation axis of small industrial robots.
The tool magazine rotation and automatic tool changing mechanism of the machining center.
The drive shaft for the indexing plate and turntable.
Used for maintenance and replacement on Fanuc 16/18/21 series systems.
In general, A06B-6093-H112 is the SVU-20 single axis driver in the Fanuc β series, which is air-cooled, fiber optic interface, 5.9A output, and drives small and medium-sized servo motors. Remember to backup the parameters before replacing the parts, otherwise the shaft cannot be moved when installed.
FANUC A06B-6093-H112伺服放大器模块 产品图片
