FANUC A16B-1100-0060-01A电源模块 PDF资料
FANUC A16B-1100-0060-01A 是发那科老款 Series 0 和 00 数控系统的电源模块，负责给整个控制系统供电。
产品特点
专为 FANUC Series 0 和 00 系统设计，把三相交流电转换成多路直流输出，给 CPU 板、I/O 模块和操作面板供电。
输出路数多，包含正 5V、正 24V、正负 12V 等，各路电压都有稳压和过载保护。
内置短路检测和过流保护，出问题的时候能及时断开，不至于把后级板子烧了。
板上有状态指示灯和测试点，正 24V、正 5V 这些关键电压能直接量，排查故障方便。
属于发那科原厂电源板，老系统上用得很多，现在市面上流通的基本是库存或拆机件。
产品参数
输入电源：三相交流 200 到 240V。
输出电压：正 5V、正 24V、正负 12V 等多路直流。
工作温度：0 到 60 度，相对湿度最高 80%。
重量：约 2 公斤。
后缀 01A 代表版本差异，功能和基础型号一致。
应用领域
FANUC Series 0 和 00 数控系统的控制柜供电。
老款加工中心和车床的维修备件替换。
发那科 3T、5M 等早期系统的电源模块替换。
伺服驱动和主轴驱动系统的控制回路供电。
工业机器人控制柜的电源部分。
总的来说，A16B-1100-0060-01A 就是发那科老系统上管供电的那块板子，把三相电转成系统需要的各路直流电
FANUC A16B-1100-0060-01A电源模块 英文介绍
FANUC A16B-1100-0060-01A is the power module of Fanuc's old Series 0 and 00 CNC systems, responsible for supplying power to the entire control system.
Product Features
Specially designed for FANUC Series 0 and 00 systems, it converts three-phase AC power into multiple DC outputs to power the CPU board, I/O modules, and operation panel.
There are multiple output channels, including positive 5V, positive 24V, positive and negative 12V, etc. Each voltage channel has voltage stabilization and overload protection.
Built in short circuit detection and overcurrent protection, which can be disconnected in a timely manner when problems occur, so as not to burn the subsequent board.
There are status indicator lights and testing points on the board, and key voltages such as positive 24V and positive 5V can be directly measured, making troubleshooting convenient.
Belonging to the original power board of Fanuc, it is widely used in old systems, and the products currently circulating on the market are mostly in stock or disassembled parts.
Product Specifications
Input power supply: three-phase AC 200 to 240V.
Output voltage: Multiple DC voltages including positive 5V, positive 24V, positive and negative 12V.
Working temperature: 0 to 60 degrees, maximum relative humidity of 80%.
Weight: Approximately 2 kilograms.
The suffix 01A represents version differences, with the same functionality as the base model.
Application Areas
Power supply for the control cabinet of FANUC Series 0 and 00 CNC systems.
Replacement of maintenance spare parts for old machining centers and lathes.
Replacement of power modules for early systems such as Fanuc 3T and 5M.
Power supply for control circuits of servo drive and spindle drive systems.
The power supply part of the industrial robot control cabinet.
In general, A16B-1100-0060-01A is the power supply board on the Fanuc old system, which converts three-phase electricity into the various DC currents required by the system
FANUC A16B-1100-0060-01A电源模块 产品图片
