BYSTRONIC E0794-5-A 印刷电路板 PDF资料
BYSTRONIC E0794-5-A 是百超 PROMON 系统里的一块印刷电路板，属于激光切割机控制系统的专用板卡。
产品特点
属于百超 PROMON 控制系统的电路板，负责系统内部的信号处理和控制。
板卡编号和百超备件号 706922 对应，找货时两个号都能用。
专用板卡，市面上流通的基本都是拆机件或库存件。
成色好的二手件比较常见，价格按状态从几百美元不等。
板子本身是原厂件，匹配百超自家系统，不用折腾兼容。
产品参数
重量大概 1 磅，约 0.45 公斤。
属于 PCB 电路板类别，用于 PROMON 控制系统。
备件编号对应 706922。
具体电压和接口参数得看实物板子上的丝印。
二手市场参考价 300 到 500 美元左右。
应用领域
百超激光切割机的 PROMON 控制系统。
激光切割机信号处理和控制指令传输。
设备维修和备件更换。
老百超设备维护翻新。
拆机件流通和维修替换场景。
总的来说，E0794-5-A 就是百超 PROMON 系统里的一块板子
BYSTRONIC E0794-5-A 印刷电路板 英文介绍
BYSTRONIC E0794-5-A is a printed circuit board in the Baichao PROMON system, which is a dedicated board for the control system of laser cutting machines.
Product Features
The circuit board belonging to the PROMON control system of Baichao is responsible for signal processing and control within the system.
The board number corresponds to the spare part number 706922 of Baichao, and both numbers can be used when searching for goods.
Specialized boards, most of which are in circulation on the market are disassembled parts or inventory parts.
Second hand items in good condition are quite common, with prices ranging from a few hundred dollars depending on their condition.
The board itself is an original factory part that matches Baichao's own system, so there is no need to tinker with compatibility.
Product Specifications
The weight is approximately 1 pound, about 0.45 kilograms.
Belonging to the category of PCB circuit boards, used for PROMON control systems.
The spare part number corresponds to 706922.
The specific voltage and interface parameters depend on the silk screen on the physical board.
The reference price for the second-hand market is around $300 to $500.
Application Areas
PROMON control system for Baichao laser cutting machine.
Signal processing and control instruction transmission of laser cutting machine.
Equipment maintenance and spare parts replacement.
Old Baichao equipment maintenance and renovation.
Scenario of dismantling parts circulation and maintenance replacement.
Overall, E0794-5-A is a board in the Baichao PROMON system
BYSTRONIC E0794-5-A 印刷电路板 产品图片
