WIELAND BAMBERG 87.210.2210.3 转换模块 PDF资料
咱们聊聊 WIELAND 87.210.2210.3 这个转换模块，它是德国 Wieland 出的一个接头转换件，专门把 IDC 排线插头转成螺丝端子。
产品特点
转换功能明确，一边接 IDC 排线插头，另一边是螺丝端子，方便现场接线。
50 针规格，触点数量固定，对应 50 芯的 IDC 排线。
直插式设计，插头方向是直的，安装方向比较规整。
替代型号是 FLK-SR 50，找货的时候可以拿这个号去对。
原厂已经停产了，市面上流通的基本是库存件。
产品参数
触点数量：50 针。
额定电压：75V。
额定电流：1A。
工作温度：0 到 50 度。
重量：大概 286 克。
应用领域
工业控制柜里做 IDC 排线到端子排的转接。
自动化设备接线，把扁平排线转成螺丝接线。
老设备维修，原装排线接口不匹配时用它过渡。
电气控制系统的信号转接，需要把 50 芯 IDC 分成单根线来接。
德国 Wieland 连接器系统里的配套转接件，用在他们的接线方案里。
总的来说，87.210.2210.3 就是个 50 针的 IDC 转螺丝端子接头，用在工业接线场合
WIELAND BAMBERG 87.210.2210.3 转换模块 英文介绍
Let's talk about the WIELAND 87.210.2210.3 conversion module, which is a connector conversion component produced in Wieland, Germany, specifically designed to convert IDC cable plugs into screw terminals.
Product Features
The conversion function is clear, with one side connected to an IDC cable plug and the other side having screw terminals for easy on-site wiring.
50 pin specification, fixed number of contacts, corresponding to 50 core IDC cable.
Direct insertion design, the plug direction is straight, and the installation direction is relatively regular.
The alternative model is FLK-SR 50, which can be used to search for goods.
The original factory has stopped production, and the products circulating in the market are mostly inventory items.
Product Specifications
Number of contacts: 50 pins.
Rated voltage: 75V.
Rated current: 1A.
Working temperature: 0 to 50 degrees.
Weight: Approximately 286 grams.
Application Areas
Transfer IDC cables to terminal blocks in industrial control cabinets.
Automated equipment wiring, convert flat ribbon cables into screw connections.
When repairing old equipment and the original wiring interface does not match, use it for transition.
The signal conversion of the electrical control system requires dividing the 50 core IDC into single wires for connection.
The matching adapter in the German Wieland connector system is used in their wiring scheme.
Overall, 87.210.2210.3 is a 50 pin IDC screw terminal connector used in industrial wiring applications
WIELAND BAMBERG 87.210.2210.3 转换模块 产品图片
