MITSUBISHI Q35B-E 主基板 PDF资料

1.产 品 资 料 介 绍：

咱们聊聊三菱 Q35B-E 这个主基板，它是 Q 系列 PLC 的底座，说白了就是用来插 CPU、电源和各种模块的架子。

产品特点

1. 5 槽主基板，带 1 个 CPU 槽、5 个 I/O 槽和 1 个电源槽，插满就是一套完整的 PLC 站。

2. 需要单独配电源，板子本身不带电源，得在左边槽位插一个 Q 系列电源模块才能用。

3. 能接扩展基板，槽位不够用可以接扩展基板扩 I/O，适合中大型系统。

4. 安装方便，可以 DIN 导轨卡上去，也可以用螺丝直接固定。

5. Q35B-E 已停产，现在用 Q35B 替代，两者功能一样，区别只是 Q35B-E 配的是英文说明书。

产品参数

1. I/O 槽数：5 个。

2. 外形尺寸：宽 245 毫米、高 98 毫米、深 44.1 毫米。

3. 重量：约 0.27 公斤。

4. 内部 5V 消耗电流：0.11 安培。

5. 安装孔：M4 螺丝孔或直径 4.5 毫米孔。

应用领域

1. 中大型自动化产线，点多了模块多了，一块主基板不够就加扩展基板，适合汽车装配、包装机械这类场合。

2. 过程控制，配过程控制 CPU 和模拟量模块，用在化工、水处理这些需要连续调节的场合。

3. 运动控制，装运动控制 CPU，最多控 32 轴，适合机床、绕线机。

4. 多 CPU 系统，同一基板上能插多个 CPU，做高速通信和分工处理。

5. 老设备维修替换，Q35B-E 停产了，用 Q35B 顶上就行，功能完全一样。

总之 Q35B-E 就是 Q 系列 PLC 的底座架子，插上电源和 CPU 就能搭一套控制系统。现在买新的用 Q35B 就行，不用纠结那个 E 后缀。

MITSUBISHI Q35B-E 主基板  英文介绍

Let's talk about the Mitsubishi Q35B-E main substrate, which is the base of the Q series PLC. In other words, it is a rack used to plug in CPUs, power supplies, and various modules.

Product Features

5-slot main substrate with 1 CPU slot, 5 I/O slots, and 1 power slot, fully plugged in to form a complete PLC station.

A separate power supply is required, and the board itself does not come with a power supply. To use it, a Q series power module must be inserted into the left slot.

Can be connected to an expansion board, but if there are not enough slots, it can be connected to an expansion board for I/O expansion, suitable for medium to large systems.

Easy to install, it can be clamped onto a DIN rail or directly fixed with screws.

Q35B-E has been discontinued and is now replaced with Q35B. Both have the same function, the only difference being that Q35B-E comes with an English manual.

Product Specifications

Number of I/O slots: 5.

Dimensions: Width 245mm, Height 98mm, Depth 44.1mm.

Weight: Approximately 0.27 kilograms.

Internal 5V consumption current: 0.11 amperes.

Installation hole: M4 screw hole or 4.5mm diameter hole.

Application Areas

Medium to large scale automated production lines, with too many modules installed, require the addition of expansion substrates when one main substrate is insufficient, making them suitable for applications such as automotive assembly and packaging machinery.

Process control, equipped with process control CPU and analog module, used in chemical and water treatment applications that require continuous adjustment.

Motion control, equipped with a motion control CPU, capable of controlling up to 32 axes, suitable for machine tools and winding machines.

A multi CPU system that can accommodate multiple CPUs on the same substrate for high-speed communication and division of labor processing.

Old equipment maintenance and replacement, Q35B-E has been discontinued, just use Q35B to top it up, the function is completely the same.

In short, Q35B-E is the base frame of the Q series PLC, which can be connected to a power supply and CPU to build a control system. Just buy a new one with Q35B now, don't worry about the E suffix.
