PILZ PSS1 302051 电源模块 PDF资料
咱们聊聊 PILZ PSS1 302051 这个电源模块，它是皮尔磁安全控制系统里的专用供电单元。
产品特点
专为 PSS 3000 和 PSS 3100 模块化安全系统设计，给整个机架的标准段和故障安全段供电。
内部带保护和监控电路，电压异常能监测，保障安全系统稳定运行。
输出多路电压，除了 5V 给模块内部用，还出 12V 和 24V 供外部传感器或继电器。
模块化插拔设计，装在 PSS 机架插槽里，维护更换方便。
原厂已停产，现在市面上流通的基本是库存或二手件。
产品参数
输入电源：24V 直流，允许负 15% 到正 20% 波动。
主输出：5V 直流，持续负载最大 5A，短路保护。
辅助输出：12V 直流 0.25A 一路，以及 24V 直流用于外部供电。
功率消耗：约 50W，效率属于开关电源级别。
环境与防护：工作温度 0 到 60 度，防护等级 IP20，重量大概 550 克。
应用领域
汽车制造和零部件产线，为急停、安全门、光栅这些安全功能供电。
机械加工和机床行业，给安全控制器和 I/O 模块提供可靠电源。
物流仓储自动化，立体仓库堆垛机和输送线的安全系统供电。
化工和石化行业，在有温度波动和电气噪声的环境下维持安全控制。
食品饮料生产线，符合卫生要求的安全控制系统供电。
总的来说，PSS1 302051 就是皮尔磁 PSS 安全系统里管供电的模块，装机架上一个，给整套安全控制器和外围传感器供上干净稳定的电。
Let's talk about the PILZ PSS1 302051 power module, which is a dedicated power supply unit in the Pilz safety control system.
Product Features
Specially designed for PSS 3000 and PSS 3100 modular safety systems, providing power to the standard and fail safe sections of the entire rack.
Equipped with internal protection and monitoring circuits, it can monitor abnormal voltage and ensure stable operation of the safety system.
Output multiple voltages, in addition to 5V for internal use of the module, 12V and 24V are also provided for external sensors or relays.
Modular plug-in design, installed in the PSS rack slot for easy maintenance and replacement.
The original factory has ceased production, and the products currently circulating in the market are mostly inventory or second-hand parts.
Product Specifications
Input power supply: 24V DC, allowing fluctuations from negative 15% to positive 20%.
Main output: 5V DC, maximum continuous load of 5A, short circuit protection.
Auxiliary output: 12V DC 0.25A one channel, and 24V DC for external power supply.
Power consumption: about 50W, efficiency belongs to the level of switching power supply.
Environment and Protection: Working temperature range from 0 to 60 degrees, protection level IP20, weight approximately 550 grams.
Application Areas
Automotive manufacturing and parts production lines provide power for safety functions such as emergency stop, safety doors, and light barriers.
Provide reliable power to safety controllers and I/O modules in the machining and machine tool industries.
Logistics warehousing automation, power supply for safety systems of three-dimensional warehouse stacker cranes and conveyor lines.
Maintain safety control in environments with temperature fluctuations and electrical noise in the chemical and petrochemical industries.
The food and beverage production line is powered by a safety control system that meets hygiene requirements.
Overall, PSS1 302051 is the module responsible for power supply in the Pirelli PSS safety system. It is mounted on a rack and provides clean and stable electricity to the entire safety controller and peripheral sensors.
