FANUC A20B-0008-0030/090 控制器电路板 PDF资料
FANUC A20B-0008-0030/090 是发那科主轴驱动系统里的一块主轴定向板，主要用来控制主轴准停定位。
产品特点
属于发那科 AC 主轴伺服单元的一部分，负责主轴的定向控制，让主轴能精确停在某个角度位置。
采用磁传感器系统，支持两级速度切换，定向精度稳定。
通常装在 A06B-6041-H002 或 A06B-6055-H002 这类中大功率驱动底座上。
属于专用板卡，坏了基本靠交换或返修，现场不建议自己修。
板子本身不带用户可维护部件，出问题找专业维修或者发那科售后。
产品参数
尺寸大概 30 厘米长、15 厘米宽、3 厘米高，重量 0.3 公斤左右。
属于 PCB 电路板类别，用于 Series 0 等 CNC 系统的主轴定向。
定向方式：磁传感器系统，支持两级速度切换。
兼容的驱动底座：A06B-6041-H002、A06B-6055-H002 等。
后缀 /090 可能代表版本或批次差异，功能和基础型号一致。
应用领域
数控机床主轴定向，换刀时让主轴停在固定角度。
加工中心自动换刀系统，配合刀库完成刀具交换。
发那科 Series 0 等老款 CNC 系统的维修备件。
主轴驱动单元故障排查时的替换件。
老机床维护翻新，找不到原厂新板时用维修件顶上。
总的来说，A20B-0008-0030/090 就是发那科主轴驱动里管定向的那块小板，换刀的时候离不开它
FANUC A20B-0008-0030/090 控制器电路板 英文介绍
FANUC A20B-0008-0030/090 is a spindle orientation plate in the Fanuc spindle drive system, mainly used to control the spindle's accurate stop positioning.
Product Features
Belonging to the Fanuc AC spindle servo unit, it is responsible for the orientation control of the spindle, allowing the spindle to accurately stop at a certain angle position.
Adopting a magnetic sensor system, supporting two-level speed switching and stable directional accuracy.
Usually installed on high-power drive bases such as A06B-6041-H002 or A06B-6055-H002.
It belongs to a dedicated board, and if it breaks, it mainly relies on exchange or repair. It is not recommended to repair it on site.
The board itself does not come with user maintainable components. If there are any problems, seek professional repair or Fanuc after-sales service.
Product Specifications
The dimensions are approximately 30 centimeters long, 15 centimeters wide, and 3 centimeters high, with a weight of around 0.3 kilograms.
Belonging to the PCB circuit board category, used for spindle orientation in CNC systems such as Series 0.
Directional method: Magnetic sensor system, supporting two-level speed switching.
Compatible driver base: A06B-6041-H002, A06B-6055-H002, etc.
The suffix/090 may represent version or batch differences, with functionality consistent with the base model.
Application Areas
CNC machine tool spindle orientation, make the spindle stop at a fixed angle when changing tools.
The automatic tool changing system of the machining center is used in conjunction with the tool magazine to complete tool exchange.
Repair spare parts for old CNC systems such as Fanuc Series 0.
Replacement parts for troubleshooting spindle drive units.
When repairing and refurbishing old machine tools and unable to find original new boards, use repair parts to top them up.
In general, A20B-0008-0030/090 is the small plate that guides the orientation of the inner tube in the Fanuc spindle drive, and it is indispensable for tool changing
FANUC A20B-0008-0030/090 控制器电路板 产品图片
