MIKRO ELEKTRONIK 01A302-00输入/输出控制器板 PDF资料
01A302-00 是 MEN Mikro Elektronik 出的 A302 系列 VMEbus 数字量 I/O 板，主要用来处理工业现场的开关信号。
产品特点
一块板子 128 路数字 I/O，分成 4 个组，每组 32 路，每组之间光耦隔离，抗干扰能力强。
每一路都能单独设成输入或输出，不用整组整组地改，用起来很灵活。
支持边沿触发中断，每个通道可以单独设定，适合需要快速响应信号的场合。
输出是高边开关，带过流和过温保护，单通道最大 1.9A，单组最大 16A，带负载能力挺强。
标准 6U VMEbus 板卡，占一个槽位，A24/D16 从设备模式。
产品参数
数字 I/O：128 路二进制信号，4 组光耦隔离单元，每组 32 通道。
输出特性：电压范围 12V 或 32V，逻辑 1 时单通道最大 1.9A，切换时间小于 200 微秒。
输入特性：电压 0 到 32V，逻辑 1 阈值约 9.2V，输入切换时间 33 到 44 微秒，耐压最高 47V。
供电：正 5V 约 106 毫安，正 3.3V 约 27 毫安，外部正 24V 约 78 毫安。
尺寸：标准双 Eurocard，233.3 毫米乘 160 毫米，重 280 克。
应用领域
工业过程控制，采集现场开关量信号或者驱动继电器、电磁阀。
汽车测试台架，处理各种传感器和执行器的数字信号。
自动化产线，做设备状态监控和逻辑控制。
需要电气隔离的工业环境，防止地环路干扰。
老式 VMEbus 系统的 I/O 扩展，替换或新增数字量通道。
总的来说，01A302-00 就是一块 VMEbus 数字量 I/O 板，亮点是 128 路灵活配置加光耦隔离，适合工业现场信号多、干扰大的场合。
MIKRO ELEKTRONIK 01A302-00输入/输出控制器板 英文介绍
01A302-00 is the A302 series VMEbus digital I/O board developed by MEN Mikro Elektronik, mainly used to process switch signals in industrial fields.
Product Features
A board with 128 digital I/O channels is divided into 4 groups, each with 32 channels. The optocouplers between each group are isolated and have strong anti-interference ability.
Each channel can be individually set as an input or output, without the need to modify the entire group, making it very flexible to use.
Support edge triggered interrupts, each channel can be individually set, suitable for situations that require fast response signals.
The output is a high side switch with overcurrent and over temperature protection, with a maximum of 1.9A per channel and 16A per group. It has strong load capacity.
Standard 6U VMEbus card, occupying one slot, A24/D16 slave device mode.
Product Specifications
Digital I/O: 128 binary signals, 4 sets of optocoupler isolation units, 32 channels per set.
Output characteristics: Voltage range of 12V or 32V, maximum 1.9A per channel at logic 1, switching time less than 200 microseconds.
Input characteristics: voltage ranging from 0 to 32V, logic 1 threshold of approximately 9.2V, input switching time of 33 to 44 microseconds, maximum withstand voltage of 47V.
Power supply: Positive 5V is about 106 milliamps, positive 3.3V is about 27 milliamps, and external positive 24V is about 78 milliamps.
Size: Standard dual Eurocard, 233.3 millimeters by 160 millimeters, weighing 280 grams.
Application Areas
Industrial process control, collecting on-site switch signals or driving relays and solenoid valves.
Automotive testing bench, processing digital signals from various sensors and actuators.
Automated production line, responsible for equipment status monitoring and logic control.
Industrial environments that require electrical isolation to prevent interference from ground loops.
I/O expansion, replacement or addition of digital channels for old VMEbus systems.
Overall, 01A302-00 is a VMEbus digital I/O board, with a highlight of 128 flexible configurations and optocoupler isolation, suitable for industrial sites with multiple signals and high interference.
MIKRO ELEKTRONIK 01A302-00输入/输出控制器板 产品图片
