AUTOMATION A437409-HV 3相电源控制器 PDF资料
AUTOMATION A437409-HV 是自动化控制柜里用的三相电源控制器，通常负责对三相电进行调压、调功或者通断控制。
产品特点
三相一体化控制，能同时管三路电，不用单独配三个单相控制器。
HV 后缀一般代表高压版本，可能支持 480V 甚至更高的三相电压输入。
调功或调压方式，常见的是晶闸管（可控硅）移相触发或者周波控制，用来加热或者调光。
带散热设计，这类控制器电流大，一般配散热片或者强制风冷。
工业级封装，装在电控柜里，防尘防触碰。
产品参数
输入电压：三相交流，具体电压看 HV 版本，可能是 380V 到 480V 范围。
输出方式：三相可控硅输出，支持移相或过零触发。
控制信号：一般接受 4 到 20 毫安、0 到 10 伏或者电位器输入。
电流容量：按型号不同，从几十安到几百安都有。
安装方式：面板安装或导轨安装，配散热底座。
应用领域
工业电加热，比如注塑机料筒、热处理炉、烘箱的温度控制。
玻璃和陶瓷行业，窑炉的三相加热调功。
半导体设备，扩散炉、烧结炉的功率调节。
电力调整器替代场景，老设备里原装调功器坏了用这个替换。
三相电机软启动或调压控制。
总的来说，A437409-HV 就是一块三相电源控制模块，核心功能是控制三相负载的功率
AUTOMATION A437409-HV 3相电源控制器 英文介绍
The Automation A437409-HV is a three-phase power controller used in automation control cabinets, typically responsible for regulating voltage, power, or on-off control of three-phase electricity.
Product Features
Three phase integrated control, capable of simultaneously managing three electrical circuits without the need for separate single-phase controllers.
The HV suffix generally represents the high voltage version, which may support three-phase voltage inputs of 480V or even higher.
The common methods of power or voltage regulation are thyristor (thyristor) phase-shift triggering or frequency control, used for heating or dimming.
Equipped with heat dissipation design, this type of controller has high current and is usually equipped with heat sinks or forced air cooling.
Industrial grade packaging, installed in the electrical control cabinet, dust-proof and touch proof.
Product Specifications
Input voltage: three-phase AC, the specific voltage depends on the HV version, which may be in the range of 380V to 480V.
Output mode: Three phase thyristor output, supporting phase-shifting or zero crossing triggering.
Control signal: Generally accepts 4 to 20mA, 0 to 10V, or potentiometer input.
Current capacity: varies from tens of amps to hundreds of amps depending on the model.
Installation method: panel installation or rail installation, equipped with a heat dissipation base.
Application Areas
Industrial electric heating, such as temperature control of injection molding machine barrels, heat treatment furnaces, and ovens.
Three phase heating and power adjustment for kilns in the glass and ceramic industry.
Power regulation of semiconductor equipment, diffusion furnaces, and sintering furnaces.
In the scenario of replacing power regulators, if the original power regulator in old equipment breaks down, use this replacement.
Three phase motor soft start or voltage regulation control.
Overall, A437409-HV is a three-phase power control module, whose core function is to control the power of three-phase loads
AUTOMATION A437409-HV 3相电源控制器 产品图片
