HAWKER ELECTRONICS AC1 1183 PCB电路板 PDF资料
HAWKER ELECTRONICS AC1 系列是英国霍克电子做的一款导电式液位控制器，AC1 1183 这个编号大概率是某个具体型号或批次。
产品特点
导电式液位控制，靠液体导电特性来检测高低水位，水和酸碱液体都能用。
切换精度很高，开关差值小于设定灵敏度的百分之五，脏水里也能稳定工作。
抗电极污垢，污水里的破布、泡沫不容易让它误动作，不会因为电极脏了就乱跳。
用低电压交流电给电极供电，防止电解腐蚀电极，延长使用寿命。
失效安全可切换，抽水用失效低模式，灌水用失效高模式，断电时能自动回到安全状态。
产品参数
灵敏度可调，范围大概 100 到 18000 欧姆之间。
工作温度零上 10 度到 50 度。
继电器触点容量 250V 交流、50Hz、功率因数 0.8 的情况下能带 5 安培。
面板安装，电源、接地和电极端子都是双份的，接线方便。
电极电缆最长能拉到 150 米。
应用领域
水处理，水箱高低水位控制。
污水处理，泵站里控制水泵启停，防止干转。
化工和食品行业，酸碱溶液、牛奶、啤酒这些导电液体的液位监控。
高液位或低液位报警，防止溢罐或者抽空。
钻孔或深井的水位控制。
总的来说，AC1 1183 就是霍克 AC1 系列里的一个液位控制板，装在水处理或者化工现场控制泵的启停。具体编号差异建议直接问 T-T Hawker 那边确认。
HAWKER ELECTRONICS AC1 1183 PCB电路板 英文介绍
The HAWKER Electronics AC1 series is a conductive liquid level controller made by Hawker Electronics in the UK. The AC1 1183 number is likely a specific model or batch.
Product Features
Conductive liquid level control relies on the conductivity of the liquid to detect high and low water levels, and can be used for both water and acid-base liquids.
The switching accuracy is very high, with a switch difference of less than 5% of the set sensitivity, and it can also work stably in dirty water.
Anti electrode dirt, rags and foam in sewage are not easy to make it malfunction, and will not jump because the electrode is dirty.
Use low-voltage AC power to supply power to the electrodes, prevent electrolytic corrosion of the electrodes, and extend their service life.
The failure safety can be switched, with a low failure mode for pumping and a high failure mode for filling. It can automatically return to a safe state when power is cut off.
Product Specifications
The sensitivity is adjustable, with a range of approximately 100 to 18000 ohms.
The working temperature ranges from 10 degrees Celsius to 50 degrees Celsius.
Under the conditions of a relay contact capacity of 250V AC, 50Hz, and a power factor of 0.8, it can carry 5 amperes.
Panel installation, power supply, grounding, and electrode terminals are all duplicated, making wiring convenient.
The electrode cable can be pulled up to a maximum length of 150 meters.
Application Areas
Water treatment, high and low water level control of water tank.
Sewage treatment, control the start and stop of water pumps in the pump station to prevent dry running.
Liquid level monitoring of conductive liquids such as acid-base solutions, milk, and beer in the chemical and food industries.
High or low liquid level alarm to prevent tank overflow or emptying.
Water level control for drilling or deep wells.
Overall, AC1 1183 is a liquid level control board in the Hawker AC1 series, installed in water treatment or chemical sites to control the start and stop of pumps. It is recommended to directly ask T-T Hawker for confirmation of the specific numbering differences.
HAWKER ELECTRONICS AC1 1183 PCB电路板 产品图片
